Overview
| Topology | Buck Converter |
| Input voltage | 12 V |
| Output 1 | 0.7 V / 10 A |
Description
The AnD7202Adaptable PMIC uses AnDAPT AmP™ advanced technology consisting of fully flexible digital fabric embedded with high performance analog blocks. The AnD7202consists of one configurable DrMOS controller, one 10A high current synchronous Buck regulator, one 6A high current synchronous Buck regulator, two Load Switches along with an integrated sequencer and four additional auxiliary LDOs. The AnD7202is fully tested and ready for use in designs. The AnD7202Buckregulatorsuse voltage-mode control. The user can modify output voltages and rail sequencing using external resistors or WebAdapter™ online tool. The sequencer can be programmed based on either timed delays or Power Good (PGOOD) signals. Adaptable PMICs provide fastest prototyping and time-to-market, while providing best-in-class performance and flexibility. The Adaptable PMIC is optimized to power high-end processors by integrating multiple power rails into single-chip designs.
Features
- Demonstrates AnD7220 or AnD7202 Adaptable PMIC:
- One DrMOS Buck Regulator
- One 10A Synchronous Buck Regulator
- One 6A Synchronous Buck Regulator
- Two LDOs (AnD7220) or two Load Switches (AnD7202)
- Four 0.2A auxiliary LDOs: 1.2V, 1.8V, 2.5V, 3.3V
- Sequencing
- WebAdapter™ or WebAmP™ Tool Downloads Configuration Files:
- .HAX file to configure the device directly
- .HEX file (Intel HEX) to program on-board flash
Typical applications
- On-demand power management, multi-rail power integration / Powering server, processor, memory, storage, network switcher and router platforms / Powering FPGA, processor, SSD, subsystem power control & sequencing
More information
All technical functions in detail
