Use the reference design search to find Würth Elektronik components recommended by the IC manufacturer for a fast and reliable development of your product!

Infineon Technologies 1ED3890MX12M | Demoboard EVAL-1ED3890MX12M

Evaluation board description and getting started guide

The Eval-1ED3890Mx12M board is designed to evaluate the functionalities and capabilities of 1ED3890MC12M or 1ED3890MU12M gate drivers ICs. This user guide will only selectively present the key features of the gate driver, and the reference manual and the datasheet to observe the full functionality and flexibility of the 1ED3890MC12M or 1ED3890MU12M gate drivers and Eval-1ED3890Mx12M.

STMicroelectronics ST-ONE | Demoboard EVLONE65W

High power density USB-PD board

The EVLONE65W is a high power density USB-PD board supporting Programmable Power Supply (PPS). The design supports wide range input voltage and can deliver five fixed PDOs and two APDOs. This board is based on ST-ONE, the world’s first digital controller embedding an Arm® Cortex® M0+ core, an offline programmable controller with synchronous rectification, and USB-PD PHY in a single package.Such a system is specifically designed to control ZVS non-complementary active clamp flyback converters to create high power density chargers and adapters with USB-PD interface.

Low-emission 36-V push-pull transformer driver

Texas Instruments SN6507

The SN6507 is a high voltage, high frequency push-pull transformer driver providing isolated power in a small solution size. The device comes with the push-pull topology’s benefits of simplicity, low EMI, and flux cancellation to prevent transformer saturation. Further space savings are achieved through duty cycle control, which reduces component count for wide input ranges, and by selecting a high switching frequency, reducing the size of the transformer.

Totem Pole CrM Controller Evaluation Board

Onsemi NCP1680 | Demoboard NCP1680 –300W PFC

The NCP1680 is a Critical Conduction Mode (CrM) Power Factor Correction (PFC) controller IC designed to drive the bridgeless Totem Pole PFC (TPFC) topology. The bridgeless totem pole PFC consists of two totem pole legs:a fast switching leg driven at the PWM switching frequency and a second leg that operates at the AC line frequency.

Xilinx Zynq UltraScale+ MPSoC Performance Optimized Reference Design PMIC

AnDAPT Inc AmP8DB6QF65 | Demoboard AmP8XEB1

The ARD_X_ZUM_C1 is a scalable power supply designed to provide power to Xilinx Zynq UltraScale+ (ZU+) MPSoC Performance optimized FPGAs.The design is scalable to support the most basic ZU2CG device with a dual-core Arm Cortex-53 application processor and dual-core Arm Cortex-R5F real-time processor to ZU19EG products that have graphics processing capabilities (GPUs) to ZU5EV devices with quad-core Arm Cortex-A53 application processor and dual-core Arm Cortex-R5 real-time processor with video processing abilities.

Automotive 3-Phase motor gate driver unit

STMicroelectronics L9908 | Demoboard AEK-MOT-3P99081

The AEK-MOT-3P99081 evaluation board is based on the SPC560P Pictus 32-bit MCU and the L9908 gate driver allowing the control of 6 N-channel FETs for brushless motors in automotive applications. The AEK-MOT-3P99081 supports independent encoder inputs and Hall sensors to detect and control motor speed.

IC Reference Design Search from Würth Elektronik

Fast, efficient, easy to use

Würth Elektronik's IC reference design search makes realizing your project easy and offers many advantages. With this application, you get free access to an extensive library of the most popular semiconductor reference designs featuring Würth Elektronik’s components.

You can find more than 10,000 IC Reference Designs featuring over 25,000 WE components on the platform, including numerous semiconductor manufacturers such as: ADI Power by Linear, Analog Devices, Infineon Technologies, Maxim Integrated, Microchip Technology, onsemi, STMicroelectronics, Texas Instruments and many more.

Easy To Use: There are several filters ready to use in order to find what you are searching for. Simply filter by IC manufacturers, IC numbers or topology like Buck, Boost, Sepic etc.. In addition, we offer a detailed parameter search, where you can filter by input voltage, switching frequency, output voltage and output current.

Find your reference design

There are many ways to find the right reference design, leading you to the most suitable electronic and electromechanical components for your Bill of material (BOM) from Würth Elektronik. On the detail page of each design, we offer the corresponding product data sheet and a direct sample order free of charge for nearly all our referenced parts. The IC reference design datasheet and link to the manufacturers page is also included, as well as lots of additional information like design description, features, and applications.

You want more?

Order a ready to use development kit and save time on your design.

Or take part in our events in cooperation with the IC manufacturers. Click here to register now.
