WE-PD SMT Power Inductor
EXTENDEDShielded
| Size | Dimensions | L (mm) | W (mm) | H (mm) | Mount | |
|---|---|---|---|---|---|---|
6033 R | 5.9 | 6.2 | 3.3 | SMT | ||
6050 R | 5.9 | 6.2 | 5 | SMT | ||
7332 | 7.3 | 7.3 | 3.2 | SMT | ||
7332 P | 7.3 | 7.4 | 3.2 | SMT | ||
7332 R | 7.3 | 7.3 | 3.2 | SMT | ||
7345 | 7.3 | 7.3 | 4.5 | SMT | ||
7345 R | 7.3 | 7.3 | 4.5 | SMT | ||
7345 P | 7.3 | 7.3 | 4.5 | SMT | ||
1030 P | 10 | 10 | 3 | SMT | ||
EXT.1050 P | 10 | 10 | 5 | SMT | ||
1245 | 12 | 12 | 4.5 | SMT | ||
1260 | 12 | 12 | 6 | SMT | ||
1260 P | 12 | 12 | 6 | SMT | ||
1280 | 12 | 12 | 8 | SMT | ||
1280 P | 12 | 12 | 8 | SMT | ||
1210 | 12 | 12 | 10 | SMT | ||
1510 | 15 | 15 | 10 | SMT |
LTSpice files
Characteristics
- AEC-Q 200 qualified
- Ultra low RDC and RAC
- Highest possible saturation current based on ferrite
- Suitable for switching frequency up to 10 MHz
- Temperature dependent parameter available on REDEXPERT
- Operating temperature: -40 °C to +125 °C / +150 °C
- Types
- WE-PD: Always offers low loss material, tight tolerances, and high saturation behavior compared to other manufacturers in the market
- WE-PD Robust: Plastic base improves the mechanical stability and efficiency
- WE-PD Performance: MnZn core improves saturation and RDC for highest efficiency
Applications
- Switch mode power supplies from 0.1 W up to 300 W
- Integrated DC/DC converter
- Ideal for switch mode power supplies with extreme high efficiency (>95%)
Application Notes
- ANP032 High Power Wireless Power Transfer for the Industrial Environment
- ANP039 Power Inductors - 8 Design Tips
- ANP047 The Behavior of Electro-Magnetic Radiation of Power Inductors in Power Management
- ANP118 Acoustic noise & Coil whine effect
- ANP135 The SEPIC with coupled and uncoupled inductors
- ANP138 Custom Rated Current Calculator
