WRIS-RSKS Thick Film Resistors

Anti-Sulfur Resistors

WRIS-RSKS Thick Film Resistors. Resistance range: 1 Ω - 10 MΩ. Long term reliability. Sulfur resistant: Tested according to ASTM-B-809.
SizeDimen­sionsL
(mm)		W
(mm)		H
(mm)		Mount
0402
 1 0.5 0.35 SMT
0603
 1.6 0.8 0.45 SMT
0805
 2 1.25 0.5 SMT
1206
 3.1 1.6 0.6 SMT
1210
 3.1 2.6 0.55 SMT

LTSpice files

Characteristics

  • Mounting style: SMT-Chip
  • Resistance range: 1 Ω - 10 MΩ
  • Resistance tolerance: ±1 %; ±5 %
  • Rated Power: 0.1 - 0.5 W
  • TCR: ±100; ±200; -200~+400 ppm/℃
  • Sulfur resistant: Tested according to ASTM-B-809
  • Long term reliability
  • Operating Temperature: -55 °C up to +155 °C
  • Size: 0402 / 0603 / 0805 / 1206 / 1210
  • AEC-Q200 qualified

Applications

  • Industrial applications
  • IT and communication applications
  • Power Supply and industrial controls
  • Applications in environments with increased sulfur contamination

Products

All
0402
0603
0805
1206
1210
Reset all
Filter article data
Filter by
Delete all
 show  articles in 5 product lines
 articles in 5 product lines
Reset all
Log in now to view availability and request availability forecasts. LOGIN
Order Code
Data­sheet
Simu­lation
Downloads
Status
R
Tol. R
PRated(mW)
TCR(ppm/ °C)
TCR(ppm/ °C)
VE(V)
L(mm)
W(mm)
H(mm)
Design Kit
SamplesAvailability & Sample
Log in now to view availability and request availability forecasts. LOGIN
560112110001
SPEC0 Ω, +0.05Ω/-0Ω, 62.5 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance0 Ω
Resistance+0.05Ω/-0Ω
Rated Power62.5 mW
–
–
–
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112140010
SPEC0 Ω, +0.05Ω/-0Ω, 330 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance0 Ω
Resistance+0.05Ω/-0Ω
Rated Power330 mW
–
–
–
Length3.1 mm
Width2.6 mm
Height0.55 mm
Design Kit –
–Check availability
560112116001
SPEC0 Ω, +0.05Ω/-0Ω, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance0 Ω
Resistance+0.05Ω/-0Ω
Rated Power100 mW
–
–
–
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112120002
SPEC0 Ω, +0.05Ω/-0Ω, 125 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance0 Ω
Resistance+0.05Ω/-0Ω
Rated Power125 mW
–
–
–
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112132007
SPEC0 Ω, +0.05Ω/-0Ω, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance0 Ω
Resistance+0.05Ω/-0Ω
Rated Power250 mW
–
–
–
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110076
SPEC1 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110132
SPEC1 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116071
SPEC1 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112132002
SPEC1 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112132024
SPEC1.1 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.1 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110058
SPEC1.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112132010
SPEC1.2 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.2 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112132014
SPEC1.8 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.8 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110057
SPEC2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112120016
SPEC2 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112132047
SPEC2 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110074
SPEC2.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110150
SPEC2.2 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116088
SPEC2.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112120018
SPEC2.2 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112132016
SPEC2.2 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112116102
SPEC2.21 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.21 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110181
SPEC3.3 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.3 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110238
SPEC3.3 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.3 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112120025
SPEC3.3 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.3 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110140
SPEC4.02 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.02 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112132031
SPEC4.3 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.3 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112116077
SPEC4.7 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112132045
SPEC4.7 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110141
SPEC4.99 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.99 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116086
SPEC4.99 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.99 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110090
SPEC5.11 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.11 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116051
SPEC5.6 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.6 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116062
SPEC8.2 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.2 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110034
SPEC10 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110075
SPEC10 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116013
SPEC10 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116033
SPEC10 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112120001
SPEC10 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112120008
SPEC10 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112132039
SPEC10 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-200 ppm/ °C
Temperature Coefficient of Resistance (max.)400 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110007
SPEC15 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance15 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116150
SPEC15 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance15 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132032
SPEC18 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance18 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110083
SPEC20 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance20 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110133
SPEC20 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance20 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116125
SPEC20 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance20 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132008
SPEC20 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance20 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110046
SPEC22 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance22 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110216
SPEC22 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance22 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116043
SPEC22 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance22 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112132042
SPEC22 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance22 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110100
SPEC22.1 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance22.1 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110219
SPEC22.6 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance22.6 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110045
SPEC24.9 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance24.9 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112132043
SPEC24.9 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance24.9 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110067
SPEC26.1 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance26.1 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110115
SPEC27.4 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance27.4 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110229
SPEC30 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance30 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110152
SPEC30.1 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance30.1 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110004
SPEC33 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance33 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110030
SPEC33 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance33 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116034
SPEC33 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance33 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132033
SPEC33 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance33 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110233
SPEC33.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance33.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116109
SPEC33.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance33.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110003
SPEC36.5 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance36.5 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110014
SPEC39 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance39 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112132037
SPEC39 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance39 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110054
SPEC40.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance40.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116130
SPEC40.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance40.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110164
SPEC42.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance42.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110165
SPEC44.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance44.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116131
SPEC44.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance44.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110017
SPEC47 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance47 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116054
SPEC47 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance47 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112120003
SPEC47 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance47 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112110002
SPEC49.9 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance49.9 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116133
SPEC49.9 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance49.9 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110119
SPEC51 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance51 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116084
SPEC51 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance51 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110073
SPEC51.1 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance51.1 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110021
SPEC56 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance56 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116142
SPEC56 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance56 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110252
SPEC56.2 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance56.2 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110170
SPEC60.4 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance60.4 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110173
SPEC64.9 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance64.9 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112132050
SPEC68 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance68 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110028
SPEC75 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance75 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110050
SPEC75 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance75 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116081
SPEC75 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance75 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112120005
SPEC75 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance75 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112116145
SPEC82 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance82 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110056
SPEC90.9 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance90.9 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110008
SPEC100 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance100 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110022
SPEC100 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance100 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116008
SPEC100 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance100 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116009
SPEC100 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance100 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112120020
SPEC100 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance100 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112120021
SPEC100 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance100 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112132023
SPEC100 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance100 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112132046
SPEC110 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance110 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110187
SPEC113 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance113 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110025
SPEC120 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance120 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110065
SPEC120 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance120 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116092
SPEC120 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance120 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116119
SPEC120 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance120 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112140009
SPEC120 Ω, ±5%, 500 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance120 Ω
Resistance±5%
Rated Power500 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width2.6 mm
Height0.55 mm
Design Kit –
–Check availability
560112110052
SPEC121 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance121 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110193
SPEC124 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance124 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110194
SPEC127 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance127 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110059
SPEC130 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance130 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116073
SPEC130 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance130 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116122
SPEC143 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance143 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110070
SPEC147 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance147 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110016
SPEC150 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance150 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110061
SPEC150 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance150 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116041
SPEC150 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance150 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116049
SPEC150 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance150 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110129
SPEC160 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance160 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116090
SPEC160 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance160 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110205
SPEC162 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance162 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110086
SPEC169 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance169 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116097
SPEC180 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance180 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110131
SPEC191 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance191 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112120010
SPEC196 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance196 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110077
SPEC200 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance200 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110211
SPEC200 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance200 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112120015
SPEC200 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance200 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112110036
SPEC220 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance220 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110047
SPEC220 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance220 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116029
SPEC220 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance220 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116126
SPEC220 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance220 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112140008
SPEC220 Ω, ±5%, 500 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance220 Ω
Resistance±5%
Rated Power500 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width2.6 mm
Height0.55 mm
Design Kit –
–Check availability
560112110148
SPEC221 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance221 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110220
SPEC232 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance232 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110009
SPEC240 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance240 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110111
SPEC240 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance240 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116089
SPEC240 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance240 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110223
SPEC249 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance249 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116099
SPEC249 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance249 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116037
SPEC270 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance270 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110230
SPEC300 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance300 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116082
SPEC300 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance300 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112120017
SPEC300 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance300 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112132044
SPEC300 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance300 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110092
SPEC301 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance301 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112120024
SPEC301 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance301 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110153
SPEC316 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance316 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110231
SPEC330 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance330 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116020
SPEC330 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance330 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116052
SPEC330 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance330 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112120014
SPEC330 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance330 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110062
SPEC332 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance332 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116100
SPEC332 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance332 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112120011
SPEC332 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance332 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110080
SPEC348 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance348 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110103
SPEC374 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance374 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116056
SPEC390 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance390 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110159
SPEC392 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance392 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110239
SPEC402 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance402 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110162
SPEC412 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance412 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110167
SPEC470 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance470 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116031
SPEC470 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance470 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116067
SPEC470 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance470 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110078
SPEC475 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance475 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116111
SPEC475 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance475 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116087
SPEC499 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance499 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110248
SPEC511 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance511 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110249
SPEC523 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance523 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110066
SPEC536 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance536 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110037
SPEC560 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance560 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116053
SPEC560 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance560 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116075
SPEC560 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance560 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110105
SPEC576 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance576 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116143
SPEC619 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance619 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110265
SPEC620 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance620 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110174
SPEC665 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance665 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110024
SPEC680 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance680 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116027
SPEC680 Ω, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance680 Ω
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132049
SPEC680 Ω, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance680 Ω
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112116115
SPEC681 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance681 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110093
SPEC698 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance698 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110262
SPEC750 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance750 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116101
SPEC750 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance750 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110108
SPEC806 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance806 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110109
SPEC825 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance825 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116136
SPEC825 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance825 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110012
SPEC1 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110023
SPEC1 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116014
SPEC1 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116016
SPEC1 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112132030
SPEC1 kΩ, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 kΩ
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112132038
SPEC1 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112120027
SPEC1000 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1000 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110094
SPEC1.07 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.07 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110185
SPEC1.1 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.1 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110188
SPEC1130 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1130 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116151
SPEC1.13 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.13 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110191
SPEC1.15 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.15 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116118
SPEC1.15 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.15 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116070
SPEC1.2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112120028
SPEC1.2 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.2 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112132053
SPEC1.2 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads4 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.2 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110091
SPEC1.21 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.21 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116120
SPEC1.21 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.21 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110143
SPEC1.27 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.27 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116121
SPEC1.27 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.27 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116065
SPEC1.3 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.3 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116152
SPEC1.37 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.37 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110198
SPEC1.4 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.4 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110200
SPEC1.47 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.47 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116123
SPEC1.47 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.47 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110027
SPEC1.5 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.5 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110095
SPEC1.5 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.5 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116038
SPEC1.5 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.5 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116083
SPEC1.5 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.5 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116094
SPEC1.6 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.6 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116095
SPEC1.62 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.62 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110096
SPEC1.69 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.69 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110206
SPEC1.74 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.74 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110208
SPEC1.78 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.78 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110209
SPEC1.8 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.8 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116032
SPEC1.8 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.8 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110145
SPEC1.82 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1.82 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112120022
SPEC1820 Ω, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance1820 Ω
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110015
SPEC2 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110064
SPEC2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116058
SPEC2 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116091
SPEC2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110212
SPEC2.05 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.05 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110213
SPEC2.1 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.1 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110011
SPEC2.2 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110087
SPEC2.2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116046
SPEC2.2 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116098
SPEC2.2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132019
SPEC2.2 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112140007
SPEC2.2 kΩ, ±5%, 500 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.2 kΩ
Resistance±5%
Rated Power500 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width2.6 mm
Height0.55 mm
Design Kit –
–Check availability
560112110048
SPEC2.26 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.26 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110221
SPEC2.32 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.32 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110060
SPEC2.4 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.4 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116061
SPEC2.4 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.4 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110224
SPEC2.49 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.49 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110069
SPEC2.61 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.61 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110149
SPEC2.67 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.67 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116127
SPEC2670 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2670 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110266
SPEC2.7 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.7 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116010
SPEC2.7 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.7 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132027
SPEC2.7 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.7 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110101
SPEC2.87 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance2.87 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116128
SPEC3 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132048
SPEC3 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110049
SPEC3.09 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.09 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110154
SPEC3.16 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.16 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110084
SPEC3240 Ω, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3240 Ω
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110053
SPEC3.3 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.3 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116047
SPEC3.3 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.3 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112120029
SPEC3.3 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.3 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110102
SPEC3.32 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.32 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116108
SPEC3.32 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.32 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110234
SPEC3.4 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.4 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110235
SPEC3.57 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.57 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110116
SPEC3.65 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.65 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110158
SPEC3.74 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.74 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110104
SPEC3.83 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.83 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116021
SPEC3.9 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.9 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110117
SPEC3.92 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance3.92 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116093
SPEC4.02 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.02 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116153
SPEC4.12 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.12 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110072
SPEC4.22 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.22 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116141
SPEC4.3 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.3 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110241
SPEC4.42 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.42 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110244
SPEC4.64 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.64 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110018
SPEC4.7 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110245
SPEC4.7 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116006
SPEC4.7 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116045
SPEC4.7 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112132020
SPEC4.7 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112140001
SPEC4.7 kΩ, ±5%, 500 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 kΩ
Resistance±5%
Rated Power500 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width2.6 mm
Height0.55 mm
Design Kit –
–Check availability
560112120030
SPEC4.7 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.7 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110005
SPEC4.75 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.75 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110247
SPEC4.99 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.99 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116132
SPEC4.99 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance4.99 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112120019
SPEC5.1 kΩ, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.1 kΩ
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112110250
SPEC5.36 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.36 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110251
SPEC5.49 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.49 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110040
SPEC5.6 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.6 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116017
SPEC5.6 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.6 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110253
SPEC5.76 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.76 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116078
SPEC5.9 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance5.9 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110254
SPEC6.04 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.04 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110171
SPEC6.19 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.19 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110256
SPEC6.2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110106
SPEC6.49 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.49 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116114
SPEC6.49 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.49 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110138
SPEC6.8 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.8 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116007
SPEC6.8 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.8 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112120031
SPEC6.8 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.8 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit –
–Check availability
560112110258
SPEC6.81 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.81 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110068
SPEC6.98 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance6.98 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110259
SPEC7.15 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance7.15 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110107
SPEC7.32 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance7.32 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110120
SPEC7.5 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance7.5 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116080
SPEC7.5 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance7.5 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110051
SPEC8.2 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.2 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116002
SPEC8.2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132051
SPEC8.2 kΩ, ±5%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.2 kΩ
Resistance±5%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit –
–Check availability
560112110110
SPEC8.25 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.25 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110177
SPEC8.45 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.45 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110264
SPEC8.66 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.66 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116137
SPEC8.87 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance8.87 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112116146
SPEC9.53 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance9.53 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110006
SPEC10 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110020
SPEC10 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116005
SPEC10 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116012
SPEC10 kΩ, ±5%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 kΩ
Resistance±5%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112120004
SPEC10 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage150 V
Length2 mm
Width1.25 mm
Height0.5 mm
Design Kit
560114
–Check availability
560112132018
SPEC10 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads8 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110182
SPEC10.2 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10.2 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110122
SPEC10.5 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance10.5 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110123
SPEC11 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance11 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116147
SPEC11 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance11 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112110189
SPEC11.3 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance11.3 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110038
SPEC12 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance12 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116040
SPEC12 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance12 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112132009
SPEC12 kΩ, ±1%, 250 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance12 kΩ
Resistance±1%
Rated Power250 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage200 V
Length3.1 mm
Width1.6 mm
Height0.6 mm
Design Kit
560114
–Check availability
560112110192
SPEC12.1 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance12.1 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112110125
SPEC12.7 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance12.7 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110126
SPEC13 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance13 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116104
SPEC13 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance13 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–Check availability
560112116036
SPEC13.3 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance13.3 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110144
SPEC14 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance14 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116096
SPEC14 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance14 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110199
SPEC14.3 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance14.3 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112110201
SPEC14.7 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance14.7 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit –
–Check availability
560112116124
SPEC14.7 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance14.7 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit –
–Check availability
560112110127
SPEC15 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance15 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage50 V
Length1 mm
Width0.5 mm
Height0.35 mm
Design Kit
560112
–Check availability
560112116035
SPEC15 kΩ, ±1%, 100 mW
Simu­lation
Availability
–
Downloads7 files

Status
ActiveProduction is active. Expected lifetime: >10 years.
iProduction is active. Expected lifetime: >10 years.
Resistance15 kΩ
Resistance±1%
Rated Power100 mW
Temperature Coefficient of Resistance (min.)-100 ppm/ °C
Temperature Coefficient of Resistance (max.)100 ppm/ °C
Limiting Element Voltage75 V
Length1.6 mm
Width0.8 mm
Height0.45 mm
Design Kit
560113
–
