WCAP-FTX2 Folienkondensatoren

X2-Capacitors

WCAP-FTX2 Folienkondensatoren

Merkmale

  • Produktserie für die Entstörung
  • Selbstheilende Eigenschaften
  • Zertifikate: ENEC 10 by VDE, cULus, CQC
  • Sicherheitsklasse: X2
  • Montagetyp: Boxed THT
  • Dielektrikum: Polypropylene
  • Rastermaß: 7.5 / 10.0 / 12.5 / 15.0 / 22.5 / 27.5 / 37.5 mm
  • Empfohlenes Lötverfahren: Wellenlöten

Anwendung

  • Sicherheitsanwendungen
  • Befilterung
  • Entstörung
  • z.B. EMV-Filter für die Stromversorgung
