Characteristics

Ready fabricated and populated USB 2.0 filter stick for test purposes
Fast testing of the filter effect on the system under test
Straightforward design implementation through BOM and layout files
Prevention of negative influence on the operating behavior due to interference emissions, electrostatic discharges (ESD) and fast transients (burst)
Data rate upto 450 Mbps
Up to 2.5 W (500 mA @ 5 V)
Filtering directly at the interface

Applications

Universal Serial Bus (USB) 2.0 Type A application

Application Notes

PCB layout files

The USB 2.0 EMC and ESD solution can be easily integrated into designs. PCB layout files (Gerber) can be downloaded here.

Download Gerber File here

Products

Order Code	Datasheet	Simulation	Downloads	Status	Product series
742792651	SPEC		9 files EDA models: Components ZIP ALT WE-CBF (rev25b).IntLib \| 260.5 KB CDS Cadence_WE-CBF (rev25a).zip \| 897.1 KB EAG Eagle_WE-CBF (rev25a).lbr \| 153.9 KB KIC KiCad_WE-CBF (rev25a).zip \| 301.3 KB ZUK Cadstar_WE-CBF (rev21a).zip \| 17.5 KB CAD files ZIP IGS WE-CBF_0603_CBF (rev1).igs \| 156.2 KB STP WE-CBF_0603_CBF (rev1).stp \| 60.5 KB Electric models ZIP PSP PSpice_WE-CBF (rev24a).zip \| 26.9 KB S S-Parameter_WE-CBF (rev22a).zip \| 2.8 MB Download all 9 files as zip archive ZIP	Active i\| Production is active. Expected lifetime: >10 years.	WE-CBF SMT EMI Suppression Ferrite Bead
744232090	SPEC		10 files EDA models: Components ZIP ALT WE-CNSW (rev25a).IntLib \| 664.5 KB CDS Cadence_WE-CNSW (rev25b).zip \| 4.2 MB EAG Eagle_WE-CNSW (rev25b).lbr \| 47.2 KB KIC KiCad_WE-CNSW (rev25a).zip \| 1.7 MB ZUK Cadstar_WE-CNSW (rev19a).zip \| 7.4 KB CAD files ZIP 3D 3D_WE-CNSW-1206 (rev1).pdf \| 331.4 KB IGS WE-CNSW_1206_CNSW (rev1).igs \| 1.2 MB STP WE-CNSW_1206_CNSW (rev1).stp \| 244.1 KB Electric models ZIP PSP PSpice_WE-CNSW (rev25b).zip \| 12.9 KB S S-Parameter_WE-CNSW (rev25a).zip \| 2.8 MB Download all 10 files as zip archive ZIP	Active i\| Production is active. Expected lifetime: >10 years.	WE-CNSW SMT Common Mode Line Filter
82400102	SPEC		7 files EDA models: Components ZIP ALT Altium_WE-TVS (rev24a).IntLib \| 575.5 KB CDS Cadence_WE-TVS (rev22a).zip \| 2.6 MB EAG Eagle_WE-TVS (rev22a).lbr \| 203.9 KB ZUK Cadstar_WE-TVS (rev19a).zip \| 12.3 KB CAD files ZIP IGS WE-TVS_High_Speed_SOT23-6L (rev1).igs \| 547.4 KB STP WE-TVS_High_Speed_SOT23-6L (rev1).stp \| 185.7 KB Electric models ZIP PSP PSpice_WE-TVS (rev25a).zip \| 27.8 KB Download all 7 files as zip archive ZIP	Active i\| Production is active. Expected lifetime: >10 years.	WE-TVS TVS Diode – High Speed Series
885012206051	SPEC		9 files EDA models: Components ZIP ALT Altium_WCAP-CSGP (rev25b).IntLib \| 912.5 KB CDS Cadence_WCAP-CSGP (rev25d).zip \| 707.7 KB EAG Eagle_WCAP-CSGP (rev25c).lbr \| 1.2 MB KIC KiCad_WCAP-CSGP (rev25a).zip \| 277.3 KB ZUK Cadstar_WCAP-CSGP (rev21c).zip \| 46.5 KB CAD files ZIP 3D 1.6x0.8x0.8x0 (rev1).pdf \| 12.3 KB IGS 1.6x0.8x0.8x0 (rev1).igs \| 76.4 KB STP Download_STP_8850122060xx (rev1).stp \| 29.4 KB Electric models ZIP PSP PSpice_WCAP-CSGP (rev25b).zip \| 336.5 KB Download all 9 files as zip archive ZIP	Active i\| Production is active. Expected lifetime: >10 years.	WCAP-CSGP MLCCs 16 V(DC)
629004113921	SPEC	–	6 files EDA models: Components ZIP ALT Altium_WR-USB (rev25a).IntLib \| 12 MB CDS Cadence_WR-COM_USB (rev25b).zip \| 61.6 MB EAG Eagle_WR-USB (rev25c).lbr \| 473.1 KB CAD files ZIP 3D 3D_629004113921 (rev1).pdf \| 211.5 KB IGS Download_IGS_629004113921 (rev1).igs \| 3.2 MB STP Download_STP_629004113921 (rev1).stp \| 769.7 KB Download all 6 files as zip archive ZIP	Active i\| Production is active. Expected lifetime: >10 years.	WR-USB Standard Connectors
62900416021	SPEC	–	7 files EDA models: Components ZIP ALT Altium_WR-USB (rev25a).IntLib \| 12 MB CDS Cadence_WR-COM_USB (rev25b).zip \| 61.6 MB EAG Eagle_WR-USB (rev25c).lbr \| 473.1 KB CAD files ZIP 3D 3D_62900416021 (rev1).pdf \| 312.6 KB IGS 62900416021 (rev1).iges \| 4.8 MB IGS Download_IGS_62900416021 (rev1).igs \| 4.4 MB STP Download_STP_62900416021 (rev1).stp \| 1.1 MB Download all 7 files as zip archive ZIP	Active i\| Production is active. Expected lifetime: >10 years.	WR-USB Standard Connectors

Order Code	Datasheet	Simulation
742792651	SPEC
744232090	SPEC
82400102	SPEC
885012206051	SPEC
629004113921	SPEC	–
62900416021	SPEC	–

Samples

Order Code	Datasheet	Simulation	Downloads	Status	Product series	Samples

Plug and Play!

To avoid reduced integrity of the data transfer due to interference and to pass EMC tests, components matched to the data lines are necessary.

For simplified implementation, the adapter stick was designed, which contains a complete filter circuit for the selected application. The filter stick is plugged into the corresponding interface for test purposes. If the test is passed with the filter stick plugged in, the filter circuit can be integrated into the system.
