Overview
| Topology | FPGA |
| IC revision | 1.1 |
Description
The ECP5™ PCI Express® Board allows you to investigate and experiment with the features of the ECP5 FieldProgrammable Gate Array. The features of the ECP5 PCI Express Board can assist you with rapid prototyping and testing of your specific designs. This document is intended to be referenced in conjunction with the demo user’s guide to demonstrate the ECP5 FPGA
Features
- PCI Express form-factor
- Allows demonstration of PCI Express x4 interconnection
- USB-B connection for UART and device programming
- One RJ45 interfaces to 10/100/1000 Ethernet to RGMII
- On-board Boot Flash
- 128M Serial SPI Flash
- 8 Gb LPDDR3 memory components (256 Mb x 32)
- Expansion connections and headers
- Allows flexibility for user prototype expansion
- Switches, LEDs and displays for demo purposes
- Lattice Diamond® Programmer configuration support
- On-board reference clock sources
- Easy power measurements
- All ECP5 rails have probable power resistors
