Ansys Library

WE Ansys Library delivers detailed, verified 3D models for use in Ansys HFSS and Ansys Icepak, helping engineers simulate and resolve RF, EMI and thermal challenges with precision before hardware testing.

The models include:

• Accurate material parameters
• High-resolution 3D geometry
• Mesh-optimized for speed and accuracy
• Validated against lab results

Available via the WE website, XML-based setup or GitHub, this library gives you flexibility, clarity, and simulation-ready performance.

What’s inside the guide:

• Model import into HFSS and Icepak
• XML file setup and usage in Ansys Desktop
• GitHub sync for ongoing updates
• Compatibility: Ansys 2023R1 and above

Download: UG018
