LTSpice files
Characteristics
- Low impedance product series
- Mounting style: V-Chip SMT
- Capacitance range: 0.1 µF ‒ 6800 µF
- Capacitance tolerance: ±20 %
- Voltage range (UR): 6.3 ‒ 100 V(DC)
- Operating temperature: -55 °C up to +105 °C
- Endurance: 2000 h @ +105 °C
- Dimensions (DxL) in mm: 4.0 x 5.5 up to 16.0 x 17.0
- Recommended soldering: Reflow soldering
Applications
- Low impedance, especially for filtering applications
- Input and output capacitor for switched-mode power supply
- Filtering
- Smoothing
- e.g. DC/DC converter, AC/DC converter, satellite receiver, control panel
Application Notes
- ANP044 Impact of the layout, components, and filters on the EMC of modern DC/DC switching controllers
- ANP071 Aluminum Electrolytic vs. Aluminum Polymer Capacitor and how its benefits are used properly
- SN008 Expected Lifetime of Aluminum Electrolytic and Aluminum Polymer Capacitor
- SN019 Afraid of aging? The effects of time on electrolytic capacitors
Products
| Order Code | Datasheet | Simulation | Downloads | C | VR (V (DC)) | Endurance (h) | Operating Temperature | IRIPPLE (mA) | Z (Ω) | ILeak (µA) | DF (%) | Ø D (mm) | L (mm) | Technical Reference | Design Kit | Samples |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 865080740003 | SPEC | 6 files | 0.22 µF | 63 | 2000 | -55 °C up to +105 °C | 2 | – | 3 | 12 | 4 | 5.5 | ASEB055R22M063DVCTAB000 | – | ||
| 865080740004 | SPEC | 6 files | 0.33 µF | 63 | 2000 | -55 °C up to +105 °C | 3 | – | 3 | 12 | 4 | 5.5 | ASEB055R33M063DVCTAB000 | – | ||
| 865080740005 | SPEC | 6 files | 0.47 µF | 63 | 2000 | -55 °C up to +105 °C | 4 | – | 3 | 12 | 4 | 5.5 | ASEB055R47M063DVCTAB000 | – | ||
| 865080640001 | SPEC | 6 files | 1 µF | 50 | 2000 | -55 °C up to +105 °C | 55 | 4.5 | 3 | 12 | 4 | 5.5 | ASEB055010M050DVCTAB000 | 865081 | ||
| 865080740006 | SPEC | 6 files | 1 µF | 63 | 2000 | -55 °C up to +105 °C | 7 | – | 3 | 12 | 4 | 5.5 | ASEB055010M063DVCTAB000 | – | ||
| 865081740001 | SPEC | 6 files | 1 µF | 80 | 2000 | -55 °C up to +105 °C | 7 | – | 3 | 10 | 4 | 5.5 | ASEB055010M080DVCTAB000 | – | ||
| 865080840001 | SPEC | 6 files | 1 µF | 100 | 2000 | -55 °C up to +105 °C | 7 | – | 3 | 10 | 4 | 5.5 | ASEB055010M100DVCTAB000 | – | ||
| 865080640002 | SPEC | 6 files | 2.2 µF | 50 | 2000 | -55 °C up to +105 °C | 55 | 4.5 | 3 | 12 | 4 | 5.5 | ASEB0552R2M050DVCTAB000 | 865081 | ||
| 865080740007 | SPEC | 6 files | 2.2 µF | 63 | 2000 | -55 °C up to +105 °C | 11 | – | 3 | 12 | 4 | 5.5 | ASEB0552R2M063DVCTAB000 | – | ||
| 865081742002 | SPEC | 6 files | 2.2 µF | 80 | 2000 | -55 °C up to +105 °C | 12 | – | 3 | 10 | 5 | 5.5 | ASEC0552R2M080DVCTBB000 | – | ||
| 865080843002 | SPEC | 6 files | 2.2 µF | 100 | 2000 | -55 °C up to +105 °C | 13 | – | 3 | 10 | 6.3 | 5.5 | ASED0552R2M100DVCTBB000 | – | ||
| 865080640003 | SPEC | 6 files | 3.3 µF | 50 | 2000 | -55 °C up to +105 °C | 55 | 4.5 | 3 | 12 | 4 | 5.5 | ASEB0553R3M050DVCTAB000 | 865081 | ||
| 865080540001 | SPEC | 6 files | 3.3 µF | 35 | 2000 | -55 °C up to +105 °C | 80 | 2.8 | 3 | 14 | 4 | 5.5 | ASEB0553R3M035DVCTAB000 | – | ||
| 865080742008 | SPEC | 6 files | 3.3 µF | 63 | 2000 | -55 °C up to +105 °C | 14 | – | 3 | 12 | 5 | 5.5 | ASEC0553R3M063DVCTBB000 | – | ||
| 865081743003 | SPEC | 6 files | 3.3 µF | 80 | 2000 | -55 °C up to +105 °C | 17 | – | 3 | 10 | 6.3 | 5.5 | ASED0553R3M080DVCTBB000 | – | ||
| 865080864003 | SPEC | 6 files | 3.3 µF | 100 | 2000 | -55 °C up to +105 °C | 20 | – | 3.3 | 10 | 6.3 | 6.1 | ASED0613R3M100DVCTBB000 | – | ||
| 865080640004 | SPEC | 6 files | 4.7 µF | 50 | 2000 | -55 °C up to +105 °C | 55 | 4.5 | 3 | 12 | 4 | 5.5 | ASEB0554R7M050DVCTAB000 | 865081 | ||
| 865080540002 | SPEC | 6 files | 4.7 µF | 35 | 2000 | -55 °C up to +105 °C | 85 | 2.5 | 3 | 14 | 4 | 5.5 | ASEB0554R7M035DVCTAB000 | – | ||
| 865080742009 | SPEC | 6 files | 4.7 µF | 63 | 2000 | -55 °C up to +105 °C | 22 | – | 3 | 12 | 5 | 5.5 | ASEC0554R7M063DVCTBB000 | – | ||
| 865081743004 | SPEC | 6 files | 4.7 µF | 80 | 2000 | -55 °C up to +105 °C | 25 | – | 3.76 | 10 | 6.3 | 5.5 | ASED0554R7M080DVCTBB000 | – | ||
| 865080845004 | SPEC | 6 files | 4.7 µF | 100 | 2000 | -55 °C up to +105 °C | 28 | – | 4.7 | 10 | 6.3 | 7.7 | ASED0774R7M100DVCTCB000 | – | ||
| 865080440001 | SPEC | 6 files | 6.8 µF | 25 | 2000 | -55 °C up to +105 °C | 70 | 2.8 | 3 | 14 | 4 | 5.5 | ASEB0556R8M025DVCTAB000 | – | ||
| 865080540003 | SPEC | 6 files | 6.8 µF | 35 | 2000 | -55 °C up to +105 °C | 88 | 2.2 | 3 | 14 | 4 | 5.5 | ASEB0556R8M035DVCTAB000 | 865081 | ||
| 865080642005 | SPEC | 6 files | 6.8 µF | 50 | 2000 | -55 °C up to +105 °C | 75 | 3.8 | 3.4 | 12 | 5 | 5.5 | ASEC0556R8M050DVCTBB000 | 865081 | ||
| 865080340001 | SPEC | 6 files | 10 µF | 16 | 2000 | -55 °C up to +105 °C | 80 | 2.2 | 3 | 16 | 4 | 5.5 | ASEB055100M016DVCTAB000 | 865080 | ||
| 865080440002 | SPEC | 6 files | 10 µF | 25 | 2000 | -55 °C up to +105 °C | 85 | 2.1 | 3 | 14 | 4 | 5.5 | ASEB055100M025DVCTAB000 | – | ||
| 865080540004 | SPEC | 6 files | 10 µF | 35 | 2000 | -55 °C up to +105 °C | 90 | 2 | 3.5 | 14 | 4 | 5.5 | ASEB055100M035DVCTAB000 | 865081 | ||
| 865080642006 | SPEC | 6 files | 10 µF | 50 | 2000 | -55 °C up to +105 °C | 95 | 2.8 | 5 | 12 | 5 | 5.5 | ASEC055100M050DVCTBB000 | – | ||
| 865080743010 | SPEC | 6 files | 10 µF | 63 | 2000 | -55 °C up to +105 °C | 40 | – | 6.3 | 12 | 6.3 | 5.5 | ASED055100M063DVCTBB000 | – | ||
| 865081745005 | SPEC | 6 files | 10 µF | 80 | 2000 | -55 °C up to +105 °C | 35 | – | 8 | 10 | 6.3 | 7.7 | ASED077100M080DVCTCB000 | – | ||
| 865080845005 | SPEC | 6 files | 10 µF | 100 | 2000 | -55 °C up to +105 °C | 35 | – | 10 | 10 | 6.3 | 7.7 | ASED077100M100DVCTCB000 | – | ||
| 865080340002 | SPEC | 6 files | 15 µF | 16 | 2000 | -55 °C up to +105 °C | 85 | 2 | 3 | 16 | 4 | 5.5 | ASEB055150M016DVCTAB000 | 865080 | ||
| 865080442003 | SPEC | 6 files | 15 µF | 25 | 2000 | -55 °C up to +105 °C | 125 | 1.9 | 3.75 | 14 | 5 | 5.5 | ASEC055150M025DVCTBB000 | – | ||
| 865080542005 | SPEC | 6 files | 15 µF | 35 | 2000 | -55 °C up to +105 °C | 140 | 1.2 | 5.25 | 14 | 5 | 5.5 | ASEC055150M035DVCTBB000 | 865081 | ||
| 865080643007 | SPEC | 6 files | 15 µF | 50 | 2000 | -55 °C up to +105 °C | 140 | 1.6 | 7.5 | 12 | 6.3 | 5.5 | ASED055150M050DVCTBB000 | 865081 | ||
| 865080340003 | SPEC | 6 files | 22 µF | 16 | 2000 | -55 °C up to +105 °C | 90 | 1.98 | 3.52 | 16 | 4 | 5.5 | ASEB055220M016DVCTAB000 | 865080 | ||
| 865080140001 | SPEC | 6 files | 22 µF | 6.3 | 2000 | -55 °C up to +105 °C | 75 | 2.2 | 3 | 24 | 4 | 5.5 | ASEB055220M6R3DVCTAB000 | – | ||
| 865080240001 | SPEC | 6 files | 22 µF | 10 | 2000 | -55 °C up to +105 °C | 80 | 2.2 | 3 | 19 | 4 | 5.5 | ASEB055220M010DVCTAB000 | – | ||
| 865080442004 | SPEC | 6 files | 22 µF | 25 | 2000 | -55 °C up to +105 °C | 145 | 1.2 | 5.5 | 14 | 5 | 5.5 | ASEC055220M025DVCTBB000 | – | ||
| 865080542006 | SPEC | 6 files | 22 µF | 35 | 2000 | -55 °C up to +105 °C | 155 | 1.1 | 7.7 | 14 | 5 | 5.5 | ASEC055220M035DVCTBB000 | 865081 | ||
| 865080643008 | SPEC | 6 files | 22 µF | 50 | 2000 | -55 °C up to +105 °C | 150 | 1.3 | 11 | 12 | 6.3 | 5.5 | ASED055220M050DVCTBB000 | 865081 | ||
| 865080745011 | SPEC | 6 files | 22 µF | 63 | 2000 | -55 °C up to +105 °C | 58 | – | 13.86 | 12 | 6.3 | 7.7 | ASED077220M063DVCTCB000 | – | ||
| 865081745006 | SPEC | 6 files | 22 µF | 80 | 2000 | -55 °C up to +105 °C | 58 | – | 17600 | 10 | 6.3 | 7.7 | ASED077220M080DVCTCB000 | – | ||
| 865080853006 | SPEC | 6 files | 22 µF | 100 | 2000 | -55 °C up to +105 °C | 85 | – | 22 | 10 | 8 | 10.5 | ASEE105220M100DVCTEB000 | – | ||
| 865080140002 | SPEC | 6 files | 27 µF | 6.3 | 2000 | -55 °C up to +105 °C | 79 | 1.98 | 3 | 24 | 4 | 5.5 | ASEB055270M6R3DVCTAB000 | 865080 | ||
| 865080342004 | SPEC | 6 files | 27 µF | 16 | 2000 | -55 °C up to +105 °C | 170 | 0.74 | 4.32 | 16 | 5 | 5.5 | ASEC055270M016DVCTBB000 | 865080 | ||
| 865080242002 | SPEC | 6 files | 27 µF | 10 | 2000 | -55 °C up to +105 °C | 125 | 1.9 | 3 | 19 | 5 | 5.5 | ASEC055270M010DVCTBB000 | – | ||
| 865080443005 | SPEC | 6 files | 27 µF | 25 | 2000 | -55 °C up to +105 °C | 200 | 0.62 | 6.75 | 14 | 6.3 | 5.5 | ASED055270M025DVCTBB000 | – | ||
| 865080543007 | SPEC | 6 files | 27 µF | 35 | 2000 | -55 °C up to +105 °C | 210 | 0.6 | 9.45 | 14 | 6.3 | 5.5 | ASED055270M035DVCTBB000 | – | ||
| 865080645009 | SPEC | 6 files | 27 µF | 50 | 2000 | -55 °C up to +105 °C | 180 | 1.2 | 13.5 | 12 | 6.3 | 7.7 | ASED077270M050DVCTCB000 | 865081 | ||
| 865080140003 | SPEC | 6 files | 33 µF | 6.3 | 2000 | -55 °C up to +105 °C | 82 | 1.9 | 3 | 24 | 4 | 5.5 | ASEB055330M6R3DVCTAB000 | – | ||
| 865080240003 | SPEC | 6 files | 33 µF | 10 | 2000 | -55 °C up to +105 °C | 90 | 1.85 | 3.3 | 19 | 4 | 5.5 | ASEB055330M010DVCTAB000 | 865080 | ||
| 865080442006 | SPEC | 6 files | 33 µF | 25 | 2000 | -55 °C up to +105 °C | 160 | 1.05 | 8.25 | 14 | 5 | 5.5 | ASEC055330M025DVCTBB000 | 865081 | ||
| 865080343005 | SPEC | 6 files | 33 µF | 16 | 2000 | -55 °C up to +105 °C | 185 | 0.6 | 5.28 | 16 | 6.3 | 5.5 | ASED055330M016DVCTBB000 | 865080 | ||
| 865080543008 | SPEC | 6 files | 33 µF | 35 | 2000 | -55 °C up to +105 °C | 240 | 0.54 | 11.55 | 14 | 6.3 | 5.5 | ASED055330M035DVCTBB000 | – | ||
| 865080645010 | SPEC | 6 files | 33 µF | 50 | 2000 | -55 °C up to +105 °C | 190 | 0.71 | 16.5 | 12 | 6.3 | 7.7 | ASED077330M050DVCTCB000 | 865081 | ||
| 865080649011 | SPEC | 6 files | 33 µF | 50 | 2000 | -55 °C up to +105 °C | 200 | 0.7 | 16.5 | 12 | 8 | 6.5 | ASEE065330M050DVCTBB000 | – | ||
| 865080753012 | SPEC | 6 files | 33 µF | 63 | 2000 | -55 °C up to +105 °C | 112 | – | 20.79 | 12 | 8 | 10.5 | ASEE105330M063DVCTEB000 | – | ||
| 865081753007 | SPEC | 6 files | 33 µF | 80 | 2000 | -55 °C up to +105 °C | 112 | – | 26.4 | 10 | 8 | 10.5 | ASEE105330M080DVCTEB000 | – | ||
| 865080857007 | SPEC | 6 files | 33 µF | 100 | 2000 | -55 °C up to +105 °C | 135 | – | 33 | 10 | 10 | 10.5 | ASEF105330M100DVCTEB000 | – | ||
| 865080140004 | SPEC | 6 files | 47 µF | 6.3 | 2000 | -55 °C up to +105 °C | 86 | 1.88 | 3 | 24 | 4 | 5.5 | ASEB055470M6R3DVCTAB000 | – | ||
| 865080342006 | SPEC | 6 files | 47 µF | 16 | 2000 | -55 °C up to +105 °C | 195 | 1.05 | 7.52 | 16 | 5 | 5.5 | ASEC055470M016DVCTBB000 | 865080 | ||
| 865080242004 | SPEC | 6 files | 47 µF | 10 | 2000 | -55 °C up to +105 °C | 165 | 1.1 | 4.7 | 19 | 5 | 5.5 | ASEC055470M010DVCTBB000 | – | ||
| 865080443007 | SPEC | 6 files | 47 µF | 25 | 2000 | -55 °C up to +105 °C | 220 | 0.56 | 11.75 | 14 | 6.3 | 5.5 | ASED055470M025DVCTBB000 | – | ||
| 865080543009 | SPEC | 6 files | 47 µF | 35 | 2000 | -55 °C up to +105 °C | 240 | 0.53 | 16.45 | 14 | 6.3 | 5.5 | ASED055470M035DVCTBB000 | 865081 | ||
| 865080645012 | SPEC | 6 files | 47 µF | 50 | 2000 | -55 °C up to +105 °C | 230 | 0.7 | 23.5 | 12 | 6.3 | 7.7 | ASED077470M050DVCTCB000 | 865081 | ||
| 865080649013 | SPEC | 6 files | 47 µF | 50 | 2000 | -55 °C up to +105 °C | 240 | 0.69 | 23.5 | 12 | 8 | 6.5 | ASEE065470M050DVCTBB000 | – | ||
| 865080753013 | SPEC | 6 files | 47 µF | 63 | 2000 | -55 °C up to +105 °C | 119 | – | 29.61 | 12 | 8 | 10.5 | ASEE105470M063DVCTEB000 | – | ||
| 865081757008 | SPEC | 6 files | 47 µF | 80 | 2000 | -55 °C up to +105 °C | 160 | – | 37.6 | 10 | 10 | 10.5 | ASEF105470M080DVCTEB000 | – | ||
| 865080862008 | SPEC | 6 files | 47 µF | 100 | 2000 | -55 °C up to +105 °C | 240 | – | 47 | 10 | 12.5 | 14 | ASEH140470M100DVCTGB000ASEH140470M100DVCTGB000 | – | ||
| 865080142005 | SPEC | 6 files | 56 µF | 6.3 | 2000 | -55 °C up to +105 °C | 150 | 1.1 | 3.53 | 24 | 5 | 5.5 | ASEC055560M6R3DVCTBB000 | 865080 | ||
| 865080343007 | SPEC | 6 files | 56 µF | 16 | 2000 | -55 °C up to +105 °C | 220 | 0.56 | 8.96 | 16 | 6.3 | 5.5 | ASED055560M016DVCTBB000 | – | ||
| 865080443008 | SPEC | 6 files | 56 µF | 25 | 2000 | -55 °C up to +105 °C | 230 | 0.54 | 14 | 14 | 6.3 | 5.5 | ASED055560M025DVCTBB000 | – | ||
| 865080243005 | SPEC | 6 files | 56 µF | 10 | 2000 | -55 °C up to +105 °C | 210 | 0.57 | 5.6 | 19 | 6.3 | 5.5 | ASED055560M010DVCTBB000 | – | ||
| 865080545010 | SPEC | 6 files | 56 µF | 35 | 2000 | -55 °C up to +105 °C | 250 | 0.49 | 19.6 | 14 | 6.3 | 7.7 | ASED077560M035DVCTCB000 | 865081 | ||
| 865080653014 | SPEC | 6 files | 56 µF | 50 | 2000 | -55 °C up to +105 °C | 300 | 0.52 | 28 | 12 | 8 | 10.5 | ASEE105560M050DVCTEB000 | 865081 | ||
| 865080142006 | SPEC | 6 files | 68 µF | 6.3 | 2000 | -55 °C up to +105 °C | 160 | 0.9 | 4.28 | 24 | 5 | 5.5 | ASEC055680M6R3DVCTBB000 | 865080 | ||
| 865080343008 | SPEC | 6 files | 68 µF | 16 | 2000 | -55 °C up to +105 °C | 230 | 0.54 | 10.88 | 16 | 6.3 | 5.5 | ASED055680M016DVCTBB000 | 865080 | ||
| 865080443009 | SPEC | 6 files | 68 µF | 25 | 2000 | -55 °C up to +105 °C | 240 | 0.48 | 17 | 14 | 6.3 | 5.5 | ASED055680M025DVCTBB000 | – | ||
| 865080243006 | SPEC | 6 files | 68 µF | 10 | 2000 | -55 °C up to +105 °C | 220 | 0.55 | 6.8 | 19 | 6.3 | 5.5 | ASED055680M010DVCTBB000 | – | ||
| 865080545011 | SPEC | 6 files | 68 µF | 35 | 2000 | -55 °C up to +105 °C | 265 | 0.4 | 23.8 | 14 | 6.3 | 7.7 | ASED077680M035DVCTCB000 | 865081 | ||
| 865080653015 | SPEC | 6 files | 68 µF | 50 | 2000 | -55 °C up to +105 °C | 320 | 0.5 | 34 | 12 | 8 | 10.5 | ASEE105680M050DVCTEB000 | 865081 | ||
| 865080142007 | SPEC | 6 files | 100 µF | 6.3 | 2000 | -55 °C up to +105 °C | 170 | 0.8 | 6.3 | 24 | 5 | 5.5 | ASEC055101M6R3DVCTBB000 | 865080 | ||
| 865080343009 | SPEC | 6 files | 100 µF | 16 | 2000 | -55 °C up to +105 °C | 255 | 0.52 | 16 | 16 | 6.3 | 5.5 | ASED055101M016DVCTBB000 | – | ||
| 865080243007 | SPEC | 6 files | 100 µF | 10 | 2000 | -55 °C up to +105 °C | 240 | 0.53 | 10 | 19 | 6.3 | 5.5 | ASED055101M010DVCTBB000 | – | ||
| 865080445010 | SPEC | 6 files | 100 µF | 25 | 2000 | -55 °C up to +105 °C | 290 | 0.38 | 25 | 14 | 6.3 | 7.7 | ASED077101M025DVCTCB000 | – | ||
| 865080545012 | SPEC | 6 files | 100 µF | 35 | 2000 | -55 °C up to +105 °C | 300 | 0.38 | 35 | 14 | 6.3 | 7.7 | ASED077101M035DVCTCB000 | 865081 | ||
| 865080449011 | SPEC | 6 files | 100 µF | 25 | 2000 | -55 °C up to +105 °C | 300 | 0.36 | 25 | 14 | 8 | 6.5 | ASEE065101M025DVCTBB000 | – | ||
| 865080653016 | SPEC | 6 files | 100 µF | 50 | 2000 | -55 °C up to +105 °C | 350 | 0.46 | 50 | 12 | 8 | 10.5 | ASEE105101M050DVCTEB000 | 865081 | ||
| 865080757014 | SPEC | 6 files | 100 µF | 63 | 2000 | -55 °C up to +105 °C | 280 | – | 63 | 12 | 10 | 10.5 | ASEF105101M063DVCTEB000 | – | ||
| 865081762009 | SPEC | 6 files | 100 µF | 80 | 2000 | -55 °C up to +105 °C | 380 | – | 80 | 10 | 12.5 | 14 | ASEH140101M080DVCTGB000 | – | ||
| 865080143008 | SPEC | 6 files | 150 µF | 6.3 | 2000 | -55 °C up to +105 °C | 235 | 0.51 | 9.45 | 24 | 6.3 | 5.5 | ASED055151M6R3DVCTBB000 | – | ||
| 865080243008 | SPEC | 6 files | 150 µF | 10 | 2000 | -55 °C up to +105 °C | 250 | 0.49 | 15 | 19 | 6.3 | 5.5 | ASED055151M010DVCTBB000 | – | ||
| 865080345010 | SPEC | 6 files | 150 µF | 16 | 2000 | -55 °C up to +105 °C | 265 | 0.45 | 24 | 16 | 6.3 | 7.7 | ASED077151M016DVCTCB000 | 865080 | ||
| 865080349011 | SPEC | 6 files | 150 µF | 16 | 2000 | -55 °C up to +105 °C | 270 | 0.44 | 24 | 16 | 8 | 6.5 | ASEE065151M016DVCTBB000 | 865080 | ||
| 865080453012 | SPEC | 6 files | 150 µF | 25 | 2000 | -55 °C up to +105 °C | 480 | 0.25 | 37.5 | 14 | 8 | 10.5 | ASEE105151M025DVCTEB000 | 865081 | ||
| 865080553013 | SPEC | 6 files | 150 µF | 35 | 2000 | -55 °C up to +105 °C | 510 | 0.24 | 52.5 | 14 | 8 | 10.5 | ASEE105151M035DVCTEB000 | 865081 | ||
| 865080657017 | SPEC | 6 files | 150 µF | 50 | 2000 | -55 °C up to +105 °C | 600 | 0.25 | 75 | 12 | 10 | 10.5 | ASEF105151M050DVCTEB000 | 865081 | ||
| 865081763010 | SPEC | 6 files | 150 µF | 80 | 2000 | -55 °C up to +105 °C | 500 | – | 120 | 10 | 16 | 17 | ASEK170151M080DVCTHB000 | – | ||
| 865080863009 | SPEC | 6 files | 150 µF | 100 | 2000 | -55 °C up to +105 °C | 500 | – | 150 | 10 | 16 | 17 | ASEK170151M100DVCTHB000 | – | ||
| 865080143009 | SPEC | 6 files | 220 µF | 6.3 | 2000 | -55 °C up to +105 °C | 240 | 0.48 | 13.86 | 24 | 6.3 | 5.5 | ASED055221M6R3DVCTBB000 | – | ||
| 865080345012 | SPEC | 6 files | 220 µF | 16 | 2000 | -55 °C up to +105 °C | 275 | 0.43 | 35.2 | 16 | 6.3 | 7.7 | ASED077221M016DVCTCB000 | 865080 | ||
| 865080245009 | SPEC | 6 files | 220 µF | 10 | 2000 | -55 °C up to +105 °C | 270 | 0.44 | 22 | 19 | 6.3 | 7.7 | ASED077221M010DVCTCB000 | – | ||
| 865080349013 | SPEC | 6 files | 220 µF | 16 | 2000 | -55 °C up to +105 °C | 285 | 0.41 | 35.2 | 16 | 8 | 6.5 | ASEE065221M016DVCTBB000 | – | ||
| 865080249010 | SPEC | 6 files | 220 µF | 10 | 2000 | -55 °C up to +105 °C | 285 | 0.4 | 22 | 19 | 8 | 6.5 | ASEE065221M010DVCTBB000 | – | ||
| 865080453013 | SPEC | 6 files | 220 µF | 25 | 2000 | -55 °C up to +105 °C | 530 | 0.22 | 55 | 14 | 8 | 10.5 | ASEE105221M025DVCTEB000 | – | ||
| 865080553014 | SPEC | 6 files | 220 µF | 35 | 2000 | -55 °C up to +105 °C | 570 | 0.21 | 77 | 14 | 8 | 10.5 | ASEE105221M035DVCTEB000 | 865081 | ||
| 865080657018 | SPEC | 6 files | 220 µF | 50 | 2000 | -55 °C up to +105 °C | 650 | 0.23 | 110 | 12 | 10 | 10.5 | ASEF105221M050DVCTEB000 | 865081 | ||
| 865080762015 | SPEC | 6 files | 220 µF | 63 | 2000 | -55 °C up to +105 °C | 300 | – | 138.6 | 12 | 12.5 | 14 | ASEH140221M063DVCTGB000 | – | ||
| 865081763011 | SPEC | 6 files | 220 µF | 80 | 2000 | -55 °C up to +105 °C | 600 | – | 176 | 10 | 16 | 17 | ASEK170221M080DVCTHB000 | – | ||
| 865080145010 | SPEC | 6 files | 330 µF | 6.3 | 2000 | -55 °C up to +105 °C | 275 | 0.36 | 20.79 | 24 | 6.3 | 7.7 | ASED077331M6R3DVCTCB000 | 865080 | ||
| 865080149011 | SPEC | 6 files | 330 µF | 6.3 | 2000 | -55 °C up to +105 °C | 290 | 0.34 | 20.79 | 24 | 8 | 6.5 | ASEE065331M6R3DVCTBB000 | 865080 | ||
| 865080353014 | SPEC | 6 files | 330 µF | 16 | 2000 | -55 °C up to +105 °C | 550 | 0.25 | 52.8 | 16 | 8 | 10.5 | ASEE105331M016DVCTEB000 | 865080 | ||
| 865080453014 | SPEC | 6 files | 330 µF | 25 | 2000 | -55 °C up to +105 °C | 570 | 0.2 | 82.5 | 14 | 8 | 10.5 | ASEE105331M025DVCTEB000 | 865081 | ||
| 865080253011 | SPEC | 6 files | 330 µF | 10 | 2000 | -55 °C up to +105 °C | 500 | 0.25 | 33 | 19 | 8 | 10.5 | ASEE105331M010DVCTEB000 | 865080 | ||
| 865080557015 | SPEC | 6 files | 330 µF | 35 | 2000 | -55 °C up to +105 °C | 650 | 0.15 | 115.5 | 14 | 10 | 10.5 | ASEF105331M035DVCTEB000 | – | ||
| 865080662019 | SPEC | 6 files | 330 µF | 50 | 2000 | -55 °C up to +105 °C | 800 | 0.21 | 165 | 12 | 12.5 | 14 | ASEH140331M050DVCTGB000 | 865081 | ||
| 865080353015 | SPEC | 6 files | 470 µF | 16 | 2000 | -55 °C up to +105 °C | 590 | 0.22 | 75.2 | 16 | 8 | 10.5 | ASEE105471M016DVCTEB000 | 865080 | ||
| 865080153012 | SPEC | 6 files | 470 µF | 6.3 | 2000 | -55 °C up to +105 °C | 450 | 0.28 | 29.61 | 24 | 8 | 10.5 | ASEE105471M6R3DVCTEB000 | 865080 | ||
| 865080253012 | SPEC | 6 files | 470 µF | 10 | 2000 | -55 °C up to +105 °C | 550 | 0.25 | 47 | 19 | 8 | 10.5 | ASEE105471M010DVCTEB000 | 865080 | ||
| 865080457015 | SPEC | 6 files | 470 µF | 25 | 2000 | -55 °C up to +105 °C | 650 | 0.15 | 117.5 | 14 | 10 | 10.5 | ASEF105471M025DVCTEB000 | – | ||
| 865080562016 | SPEC | 6 files | 470 µF | 35 | 2000 | -55 °C up to +105 °C | 1100 | 0.08 | 164.5 | 14 | 12.5 | 14 | ASEH140471M035DVCTGB000 | 865081 | ||
| 865080763016 | SPEC | 6 files | 470 µF | 63 | 2000 | -55 °C up to +105 °C | 630 | – | 296.1 | 12 | 16 | 17 | ASEK170471M063DVCTHB000 | – | ||
| 865080153013 | SPEC | 6 files | 680 µF | 6.3 | 2000 | -55 °C up to +105 °C | 500 | 0.25 | 42.84 | 24 | 8 | 10.5 | ASEE105681M6R3DVCTEB000 | 865080 | ||
| 865080357016 | SPEC | 6 files | 680 µF | 16 | 2000 | -55 °C up to +105 °C | 720 | 0.16 | 108.8 | 16 | 10 | 10.5 | ASEF105681M016DVCTEB000 | 865080 | ||
| 865080257013 | SPEC | 6 files | 680 µF | 10 | 2000 | -55 °C up to +105 °C | 680 | 0.2 | 68 | 19 | 10 | 10.5 | ASEF105681M010DVCTEB000 | 865080 | ||
| 865080562017 | SPEC | 6 files | 680 µF | 35 | 2000 | -55 °C up to +105 °C | 1100 | 0.08 | 238 | 14 | 12.5 | 14 | ASEH140681M035DVCTGB000 | 865081 | ||
| 865080153014 | SPEC | 6 files | 1000 µF | 6.3 | 2000 | -55 °C up to +105 °C | 530 | 0.2 | 63 | 24 | 8 | 10.5 | ASEE105102M6R3DVCTEB000 | 865080 | ||
| 865080257014 | SPEC | 6 files | 1000 µF | 10 | 2000 | -55 °C up to +105 °C | 740 | 0.15 | 100 | 19 | 10 | 10.5 | ASEF105102M010DVCTEB000 | 865080 | ||
| 865080462016 | SPEC | 6 files | 1000 µF | 25 | 2000 | -55 °C up to +105 °C | 1100 | 0.08 | 250 | 14 | 12.5 | 14 | ASEH140102M025DVCTGB000 | 865081 | ||
| 865080663020 | SPEC | 6 files | 1000 µF | 50 | 2000 | -55 °C up to +105 °C | 1000 | 0.078 | 500 | 12 | 16 | 17 | ASEK170102M050DVCTHB000 | 865081 | ||
| 865080157015 | SPEC | 6 files | 1200 µF | 6.3 | 2000 | -55 °C up to +105 °C | 600 | 0.16 | 75.6 | 24 | 10 | 10.5 | ASEF105122M6R3DVCTEB000 | 865080 | ||
| 865080157016 | SPEC | 6 files | 1500 µF | 6.3 | 2000 | -55 °C up to +105 °C | 650 | 0.13 | 94.5 | 24 | 10 | 10.5 | ASEF105152M6R3DVCTEB000 | 865080 | ||
| 865080362017 | SPEC | 6 files | 1500 µF | 16 | 2000 | -55 °C up to +105 °C | 1100 | 0.08 | 240 | 16 | 12.5 | 14 | ASEH140152M016DVCTGB000 | 865080 | ||
| 865080563018 | SPEC | 6 files | 1500 µF | 35 | 2000 | -55 °C up to +105 °C | 1250 | 0.052 | 525 | 14 | 16 | 17 | ASEK170152M035DVCTHB000 | 865081 | ||
| 865080262015 | SPEC | 6 files | 2200 µF | 10 | 2000 | -55 °C up to +105 °C | 1100 | 0.08 | 220 | 19 | 12.5 | 14 | ASEH140222M010DVCTGB000 | 865080 | ||
| 865080463017 | SPEC | 6 files | 2200 µF | 25 | 2000 | -55 °C up to +105 °C | 1250 | 0.052 | 550 | 14 | 16 | 17 | ASEK170222M025DVCTHB000 | 865081 | ||
| 865080162017 | SPEC | 6 files | 3300 µF | 6.3 | 2000 | -55 °C up to +105 °C | 1100 | 0.08 | 207.9 | 24 | 12.5 | 14 | ASEH140332M6R3DVCTGB000 | 865080 | ||
| 865080363018 | SPEC | 6 files | 3300 µF | 16 | 2000 | -55 °C up to +105 °C | 1250 | 0.052 | 528 | 16 | 16 | 17 | ASEK170332M016DVCTHB000 | 865080 | ||
| 865080263016 | SPEC | 6 files | 4700 µF | 10 | 2000 | -55 °C up to +105 °C | 1250 | 0.052 | 470 | 19 | 16 | 17 | ASEK170472M010DVCTHB000 | 865080 | ||
| 865080163018 | SPEC | 6 files | 6800 µF | 6.3 | 2000 | -55 °C up to +105 °C | 1250 | 0.052 | 428.4 | 24 | 16 | 17 | ASEK170682M6R3DVCTHB000 | 865080 |
| Order Code | Datasheet | Simulation |
|---|---|---|
| 865080740003 | SPEC | |
| 865080740004 | SPEC | |
| 865080740005 | SPEC | |
| 865080640001 | SPEC | |
| 865080740006 | SPEC | |
| 865081740001 | SPEC | |
| 865080840001 | SPEC | |
| 865080640002 | SPEC | |
| 865080740007 | SPEC | |
| 865081742002 | SPEC | |
| 865080843002 | SPEC | |
| 865080640003 | SPEC | |
| 865080540001 | SPEC | |
| 865080742008 | SPEC | |
| 865081743003 | SPEC | |
| 865080864003 | SPEC | |
| 865080640004 | SPEC | |
| 865080540002 | SPEC | |
| 865080742009 | SPEC | |
| 865081743004 | SPEC | |
| 865080845004 | SPEC | |
| 865080440001 | SPEC | |
| 865080540003 | SPEC | |
| 865080642005 | SPEC | |
| 865080340001 | SPEC | |
| 865080440002 | SPEC | |
| 865080540004 | SPEC | |
| 865080642006 | SPEC | |
| 865080743010 | SPEC | |
| 865081745005 | SPEC | |
| 865080845005 | SPEC | |
| 865080340002 | SPEC | |
| 865080442003 | SPEC | |
| 865080542005 | SPEC | |
| 865080643007 | SPEC | |
| 865080340003 | SPEC | |
| 865080140001 | SPEC | |
| 865080240001 | SPEC | |
| 865080442004 | SPEC | |
| 865080542006 | SPEC | |
| 865080643008 | SPEC | |
| 865080745011 | SPEC | |
| 865081745006 | SPEC | |
| 865080853006 | SPEC | |
| 865080140002 | SPEC | |
| 865080342004 | SPEC | |
| 865080242002 | SPEC | |
| 865080443005 | SPEC | |
| 865080543007 | SPEC | |
| 865080645009 | SPEC | |
| 865080140003 | SPEC | |
| 865080240003 | SPEC | |
| 865080442006 | SPEC | |
| 865080343005 | SPEC | |
| 865080543008 | SPEC | |
| 865080645010 |
