WR-TBL Series 357B - 3.81 mm Double Level Horizontal Male PCB Header with Flanges

Kind Properties
Pitch3.81 mm
Material Properties
Insulator MaterialPA66
Insulator Flammability RatingUL94 V-0
Contact MaterialBrass
Contact PlatingTin
General Information
Operating Temperature-40 up to +105 °C
ComplianceRoHS
Electrical Properties
IR UL10 A
Working Voltage300 V (AC)
Working Voltage [UL]300 V (AC)
Withstanding Voltage [cULus]2000 V (AC)
Contact Resistance [cULus]20 mΩ
Certification
cULus ApprovalE315414

Products

Order Code Data­sheet DownloadsPinsApplicationPCB/Cable/PanelModularityTypeIR
(A)
Design Kit Samples
691357310004B
3D ALT EAG CAD 4 Pluggable PCB No Double Level Horizontal 10612690
691357310006B
3D ALT EAG CAD 6 Pluggable PCB No Double Level Horizontal 10
691357310008B
3D ALT EAG CAD 8 Pluggable PCB No Double Level Horizontal 10
691357310010B
3D ALT EAG CAD 10 Pluggable PCB No Double Level Horizontal 10
691357310012B
IGE STE 3D ALT EAG CAD 12 Pluggable PCB No Double Level Horizontal 10
Order Code Data­sheet
691357310004B
691357310006B
691357310008B
691357310010B
691357310012B
Samples
Order Code Data­sheet DownloadsPinsApplicationPCB/Cable/PanelModularityTypeIR
(A)
Design Kit Samples

Assortments

Articles from this product series can be found in the following assortments:
