Characteristics
Reference Designs
- RD006 3 W Dual-output isolated auxiliary supply for communication interfaces and measurement systems
| Article Properties | |
|---|---|
| Pins | 2 pcs |
| Material Properties | |
|---|---|
| Insulator Material | PBT |
| Insulator Flammability Rating | UL94 V-0 |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Contact Type | Stamped |
| General Information | |
|---|---|
| Operating Temperature | -25 °C up to +105 °C |
| Compliance | Lead free / RoHS |
| Pitch | 2 mm |
| Durability | 25 Mating cycles |
| Gender | Jumper |
| Electrical Properties | |
|---|---|
| IR | 1 A |
| Withstanding Voltage | 650 V (AC) |
| Contact Resistance | 30 mΩ |
| RISO | 1000 MΩ |
| Packaging Properties | |
|---|---|
| Packaging | Bag |
Products
| Order Code | Datasheet | Downloads | Status | Pins (pcs) | Gender | IR (A) | Packaging | Design Kit | Samples | |
|---|---|---|---|---|---|---|---|---|---|---|
 | 60800213421 | SPEC | 3 files | Active i| Production is active. Expected lifetime: >10 years. | 2 | Jumper | 3 | Bag | 612690 613001 |
| Order Code | Datasheet | |
|---|---|---|
| 60800213421 | SPEC |
| Samples |
|---|
| Order Code | Datasheet | Downloads | Status | Pins (pcs) | Gender | IR (A) | Packaging | Design Kit | Samples |
|---|
