WR-TBL Serie 3127 - 5.00 mm Open Horizontal PCB Header

Kind Properties
Pitch 5 mm
Material Properties
Insulator Material PBT
Insulator Flammability Rating UL94 V-0
Contact Material Brass
Contact Plating Tin
General Information
Operating Temperature -40 up to +105 °C
Compliance RoHS
Electrical Properties
IR cULus 20 A
IR VDE 20 A
Working Voltage [cULus] 300 V (AC)
Working Voltage [VDE] 300 V (AC)
Withstanding Voltage [cULus] 1600 V (AC)
Withstanding Voltage [VDE] 2500 V (AC)
Contact Resistance [cULus] 20 mΩ
Contact Resistance [VDE] 20 mΩ
Certification
cULus Approval E315414
VDE Approval 40023195

Products

Order Code SPEC Downloads Application PCB/Cable/Panel Modularity Type Pins Design Kit Samples
691312710003
STE 3D ALT EAG IGS CAD Pluggable PCB No Horizontal 3
691312710005
STE 3D ALT EAG IGS CAD Pluggable PCB No Horizontal 5
691312710006
STE 3D ALT EAG IGS CAD Pluggable PCB No Horizontal 6
691312710008
STE 3D ALT EAG IGS CAD Pluggable PCB No Horizontal 8
691312710002
IGE STE 3D ALT EAG CAD Pluggable PCB No Horizontal 2 691001
691312710004
IGE STE 3D ALT EAG CAD Pluggable PCB No Horizontal 4
691312710007
IGE STE 3D ALT EAG CAD Pluggable PCB No Horizontal 7
691312710012
IGE STE 3D ALT EAG CAD Pluggable PCB No Horizontal 12
Order Code SPEC
691312710003
691312710005
691312710006
691312710008
691312710002
691312710004
691312710007
691312710012
Samples
Order Code SPEC Downloads Application PCB/Cable/Panel Modularity Type Pins Design Kit Samples

Assortments

Articles from this product series can be found in the following assortments:
