WR-MPC3 Single Row Male Vertical Header

Kind Properties
Pitch 3 mm
Gender Male
Material Properties
Insulator Material LCP
Insulator Flammability Rating UL94 V-0
Color Black
Contact Material Copper Alloy
Contact Plating Tin
Contact Type Stamped
General Information
Operating Temperature -40 up to +105 °C
Compliance RoHS
Working Voltage 250 V (AC)
Withstanding Voltage 1500 V (AC)
Contact Resistance 10 mΩ
RISO 1000 MΩ
Certification
UL Approval E323964
Wire Properties
Packaging Tube

Products

Order Code Data­sheet Downloads Pins Pitch
(mm)
Gender Type Rows Mount IR 1
(A)
Working Voltage
(V (AC))
PCB/Cable/Panel Contact Resistance
(mΩ)
Tol. R L
(mm)
Packaging Design Kit Samples
66200211122
STE 3D ALT EAG IGS CAD 2 3 Male Vertical Single THT 5 250 PCB 10 max. 9.65 Tube 662001
66200311122
STE 3D ALT EAG IGS CAD 3 3 Male Vertical Single THT 5 250 PCB 10 max. 12.65 Tube 662001
66200411122
STE 3D ALT EAG IGS CAD 4 3 Male Vertical Single THT 5 250 PCB 10 max. 15.65 Tube 662001
66200511122
STE 3D ALT EAG IGS CAD 5 3 Male Vertical Single THT 5 250 PCB 10 max. 18.65 Tube 662001
66200611122
STE 3D ALT EAG IGS CAD 6 3 Male Vertical Single THT 5 250 PCB 10 max. 21.65 Tube 662001
66200711122
STE 3D ALT EAG IGS CAD 7 3 Male Vertical Single THT 5 250 PCB 10 max. 24.65 Tube 612690
662001
66200811122
STE 3D ALT EAG IGS CAD 8 3 Male Vertical Single THT 5 250 PCB 10 max. 27.65 Tube 662001
66200911122
STE 3D ALT EAG IGS CAD 9 3 Male Vertical Single THT 5 250 PCB 10 max. 30.65 Tube 662001
66201011122
STE 3D ALT EAG IGS CAD 10 3 Male Vertical Single THT 5 250 PCB 10 max. 33.65 Tube 662001
66201111122
STE 3D ALT EAG IGS CAD 11 3 Male Vertical Single THT 5 250 PCB 10 max. 36.65 Tube 662001
66201211122
STE 3D ALT EAG IGS CAD 12 3 Male Vertical Single THT 5 250 PCB 10 max. 39.65 Tube 662001
Order Code Data­sheet
66200211122
66200311122
66200411122
66200511122
66200611122
66200711122
66200811122
66200911122
66201011122
66201111122
66201211122
Samples
Order Code Data­sheet Downloads Pins Pitch
(mm)
Gender Type Rows Mount IR 1
(A)
Working Voltage
(V (AC))
PCB/Cable/Panel Contact Resistance
(mΩ)
Tol. R L
(mm)
Packaging Design Kit Samples

Assortments

Articles from this product series can be found in the following assortments:
