| Kind Properties | |
|---|---|
| P | 5.08 mm |
| Material Properties | |
|---|---|
| Isolationsmaterial | PA66 |
| Isolation Brennbarkeitsklasse | UL94 V-0 |
| Isolationsfarbe | Grün |
| Anschlussmaterial | Kupferlegierung |
| Anschlussbeschictung | verzinnte Oberfläche |
| General Information | |
|---|---|
| Betriebstemperatur | -40 up to +105 °C |
| Electrical Properties | |
|---|---|
| IR UL | 16 A |
| Arbeitsspannung [UL] | 300 V (AC) |
| Spannungsfestigkeit [UL] | 2500 V (AC) |
| Kontaktwiderstand [UL] | 20 mΩ |
| Certification | |
|---|---|
| UL-Zulassung | E315414 |
Artikeldaten
| Artikel Nr. | SPEC | Downloads | Anwendung | PCB/Kabel/Panel | Modularity | Typ | Pins | Muster |
|---|---|---|---|---|---|---|---|---|
| 691305540002 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 2 | |
| 691305540004 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 4 | |
| 691305540005 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 5 | |
| 691305540006 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 6 | |
| 691305540007 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 7 | |
| 691305540008 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 8 | |
| 691305540009 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 9 | |
| 691305540010 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 10 | |
| 691305540003 |
|
IGE STE 3D ALT EAG CAD | Pluggable | PCB | Nein | Horizontal | 3 |
| Artikel Nr. | SPEC |
|---|---|
| 691305540002 |
|
| 691305540004 |
|
| 691305540005 |
|
| 691305540006 |
|
| 691305540007 |
|
| 691305540008 |
|
| 691305540009 |
|
| 691305540010 |
|
| 691305540003 |
|
