WE-SPE Single Pair Ethernet

Characteristics

Test voltage of 2250 V(DC) / 1 min.
Available in different footprints
Operating temperature: -40 °C up to +125 °C

Applications

Isolation of industrial interfaces
Single Pair Ethernet (SPE)
Single Pair Ethernet with Power over Data Line (SPE + PoDL)

More information about Single Pair Ethernet

Thanks to the Single Pair Ethernet (SPE) standard with ranges of up to 1000 meters, many new use cases are possible. Learn more about Single Pair Ethernet in our Application Guide.

Products

Order Code	Datasheet	Downloads	Status	V_T (V (DC))	Pins (pcs)	L (mH)	C_{WW 1} (pF)	Mount	Samples
749070010	SPEC	7 files EDA models: Components ZIP ALT Altium_WE-SPE (rev25a).IntLib \| 161 KB CDS Cadence_WE-SPE (rev25a).zip \| 662.6 KB EAG Eagle_WE-SPE (rev25a).lbr \| 21.7 KB KIC KiCad_WE-SPE (rev25a).zip \| 206.2 KB CAD files ZIP 3D 749070010_3D (rev1).pdf \| 44.7 KB IGS 749070010 (rev1).igs \| 1 MB STP 749070010 (rev1).stp \| 375.4 KB Download all 7 files as zip archive ZIP	New i\| Product is new in our portfolio and production is active. Expected lifetime: >10 years.	2250	4	2.2	18	SMT
749070011	SPEC	7 files EDA models: Components ZIP ALT Altium_WE-SPE (rev25a).IntLib \| 161 KB CDS Cadence_WE-SPE (rev25a).zip \| 662.6 KB EAG Eagle_WE-SPE (rev25a).lbr \| 21.7 KB KIC KiCad_WE-SPE (rev25a).zip \| 206.2 KB CAD files ZIP 3D 749070011_3D (rev1).pdf \| 45 KB IGS 749070011 (rev1).igs \| 1.7 MB STP 749070011 (rev1).stp \| 560.9 KB Download all 7 files as zip archive ZIP	New i\| Product is new in our portfolio and production is active. Expected lifetime: >10 years.	2250	8	2.2	18	SMT

Order Code	Datasheet
749070010	SPEC
749070011	SPEC
