WE-GFH High Frequency SMT Inductor

Size	L (mm)	W (mm)	H (mm)	Mount
2520	2.5	2	1.8	SMT
3225	3.2	2.5	2.2	SMT
4532	4.5	3.2	3.2	SMT

LTSpice files

LT
LTSpice_WE-GFH (rev24a).zip
|
2.7 KB

Characteristics

Chip SMT inductance
Lower RDC for the same type
Higher current supporting than standard form
Small type 2.5 mm x 2.0 mm
Operating temperature: -40°C to +105°C (Size 2520)
Operating Temperature: -40°C to +125°C (Size 3225 and 4532 )

Applications

HF Circuits
HF Filtering Applications
Acoustic Filtering Applications

Application Notes

Products

All

2520

3225

4532
