WR-TBL Serie 2157 - 5.00 mm Vertical Entry Modular

Kind Properties
Pitch 5 mm
Material Properties
Insulator Material PA66
Insulator Flammability Rating UL94 V-0
Insulator Color Green
Contact Material Brass
Contact Plating Copper over Zinc
Terminal Screw Material Steel
Terminal Screw Plating Zinc
Wire Guard Material Brass
General Information
Operating Temperature -40 up to +105 °C
Compliance Lead free / RoHS
Electrical Properties
IR cULus 20 A
Working Voltage [cULus] 300 V (AC)
Withstanding Voltage [cULus] 1600 V (AC)
Contact Resistance [cULus] 20 mΩ
Mechanical Properties
Wire Strip Length 6 up to 7 (mm)
Screw M3
Certification
cULus Approval E315414
UL Approval E315414
Packaging Properties
Packaging Box

Products

Order Code SPEC Downloads Application PCB/Cable/Panel Modularity Type Pins Wire Section Design Kit Samples
691215700002
STE 3D ALT EAG IGS Rising Cage Clamp PCB Yes Vertical 2 30 to 12 (AWG) 0.0509 to 3.31 (mm²)
691215700003
STE 3D ALT EAG IGS Rising Cage Clamp PCB Yes Vertical 3 30 to 12 (AWG) 0.0509 to 3.31 (mm²) 691001
Order Code SPEC
691215700002
691215700003
Samples
Order Code SPEC Downloads Application PCB/Cable/Panel Modularity Type Pins Wire Section Design Kit Samples
