| Material Properties | |
|---|---|
| Cover Material | LCP |
| Cover Flammability Rating | UL94 V-0 |
| Base Material | LCP |
| Base Flammability Rating | UL94 V-0 |
| Actuator Material | PA66 |
| Actuator Flammability Rating | UL94 V-0 |
| Terminal Material | Copper Alloy |
| Terminal Plating | Gold |
| Electrical Properties | |
|---|---|
| IR | 200 mA |
| VR | 42 V (DC) |
| Contact Resistance Initial | 80 mΩ |
| RISO | 100 MΩ |
| Withstanding Voltage | 250 V (AC) |
| Mechanical Properties | |
|---|---|
| Electrical Life | 10000 Steps |
| Actuator Type | Cross Type |
| General Information | |
|---|---|
| Operating Temperature | -40 °C up to +85 °C |
| Washable | Yes |
| Ingress Protection Code | IP67 |
Products
| Order Code | Datasheet | Downloads | Status | Number of Position (Value) | Code | Ingress Protection Code | Actuator Color | Samples | |
|---|---|---|---|---|---|---|---|---|---|
 | 428511510810 | SPEC | 6 files | New i| Product is new in our portfolio and production is active. Expected lifetime: >10 years. | 10 | Real Code | IP67 | Light Grey | |
 | 428511510811 | SPEC | 6 files | New i| Product is new in our portfolio and production is active. Expected lifetime: >10 years. | 10 | Complement Code | IP67 | Blue | |
 | 428511510816 | SPEC | 6 files | New i| Product is new in our portfolio and production is active. Expected lifetime: >10 years. | 16 | Real Code | IP67 | Light Grey | |
 | 428511510817 | SPEC | 6 files | New i| Product is new in our portfolio and production is active. Expected lifetime: >10 years. | 16 | Complement Code | IP67 | Blue |
