| General Information | |
|---|---|
| Operating Temperature | -40 °C up to +85 °C |
| Type | Right Angled |
| Material Properties | |
|---|---|
| Insulator Material | PA9T |
| Insulator Flammability Rating | UL94 V-0 |
| Insulator Color | Black |
| Contact Material | Copper Alloy |
| Contact Type | Stamped |
| Shielding Material | Brass |
| Shielding Plating | Nickel (Ni) |
| Center Pin Plating | Gold |
| Tip Spring Material | Tin |
| Shunt Terminal Plating | Tin |
| Electrical Properties | |
|---|---|
| Working Voltage | 20 V (DC) |
| Withstanding Voltage | 500 V (AC) |
| Contact Resistance | 30 mΩ |
| RISO | 100 MΩ |
| Certification | |
|---|---|
| UL Approval | E323964 |
| Packaging Properties | |
|---|---|
| Packaging | Tape and Reel |
Products
| Order Code | Datasheet | Downloads | Status | Mount | Type | IR (A) | Working Voltage (V (DC)) | Packaging | Design Kit | Samples |
|---|---|---|---|---|---|---|---|---|---|---|
| 694105309102 | SPEC | 7 files | Active i| Production is active. Expected lifetime: >10 years. | THT | Right Angled | 5.5 | 20 | Tape and Reel | 612690 694001 |
| Order Code | Datasheet |
|---|---|
| 694105309102 | SPEC |
| Samples |
|---|
| Order Code | Datasheet | Downloads | Status | Mount | Type | IR (A) | Working Voltage (V (DC)) | Packaging | Design Kit | Samples |
|---|
