WE-XTAL Quartz Crystal EXTENDED

 SizeL
(mm)
W
(mm)
H
(mm)
IQXC-26 1.6 1.2 0.45
EXT. IQXC-42 2 1.6 0.5
CFPX-218 2.5 2 0.6
EXT. CFPX-180 3.2 2.5 0.8
EXT. CFPX-104 5 3.2 1
12SMX 7 5 1.4
HC49 11.05 4.65 13.46
HC49/4H 11.05 4.7 4.1
HC49/4HSMX 13.4 4.9 4.3

Characteristics

  • SMT and THT models
  • Hermetically sealed
  • Frequencies between 1.8432 MHz and 50 MHz
  • Tolerances down to ±10 ppm available
  • Maximum operating temperatures range: -40 °C to 125 °C
  • Stabilities down to ±10 ppm available

Applications

  • Microprocessor
  • Wireless Communication Devices
  • Industrial Devices
  • Wired Communication (e.g. Ethernet and USB)
  • IoT
  • Optical Network
  • Audio and Multimedia Devices
  • Test and Measurement Equipment
  • Navigation and Locators
  • Wearables

Products

All
IQXC-26
IQXC-42
CFPX-218
CFPX-180
CFPX-104
12SMX
HC49
HC49/4H
HC49/4HSMX
Order Code Data­sheet Downloadsf
(MHz)
Tol. fStability
(ppm)
Cload
(pF)
Operating TemperatureDesign Kit Samples
830003033BSPEC
4 files 1.8432 ±20ppm 50 30 -10 up to +60 °C830003
830003037BSPEC
4 files 2 ±50ppm 100 20 0 up to +50 °C
830003044BSPEC
4 files 2.4576 ±20ppm 50 30 -10 up to +60 °C830003
830024985BSPEC
4 files 3.2768 ±30ppm 50 12 -10 up to +60 °C830003
830028430SPEC
4 files 3.2768 ±30ppm 30 18 -20 up to +70 °C
830003051BSPEC
4 files 3.2768 ±20ppm 30 12 -10 up to +60 °C
830003056BSPEC
4 files 3.579545 ±20ppm 50 20 -10 up to +60 °C
830003058SPEC
4 files 3.579545 ±30ppm 50 16 -10 up to +60 °C830003
830003063BSPEC
4 files 3.579545 ±30ppm 50 20 -20 up to +70 °C830003
830003257BSPEC
4 files 3.6864 ±20ppm 50 30 -10 up to +60 °C
830003260SPEC
4 files 3.6864 ±30ppm 50 16 -10 up to +60 °C830003
830003263BSPEC
4 files 3.6864 ±30ppm 50 30 -20 up to +70 °C830003
830030798SPEC
4 files 3.6864 ±30ppm 50 16 -40 up to +85 °C
830033158SPEC
4 files 3.6864 ±30ppm 50 18 -20 up to +70 °C
830003068BSPEC
4 files 4 ±20ppm 50 30 -10 up to +60 °C
830003071SPEC
4 files 4 ±30ppm 50 16 -10 up to +60 °C830003
830003074BSPEC
4 files 4 ±20ppm 50 30 -10 up to +60 °C830003
830011300SPEC
4 files 4 ±30ppm 50 30 -10 up to +60 °C830003
830024940SPEC
4 files 4 ±30ppm 50 18 -20 up to +70 °C
830027298BSPEC
4 files 4 ±30ppm 50 18 -20 up to +70 °C830003
830034654SPEC
4 files 4 ±20ppm 50 18 -20 up to +70 °C
830003084BSPEC
4 files 4.096 ±30ppm 50 30 -10 up to +60 °C
830003086BSPEC
4 files 4.194304 ±20ppm 30 12 -10 up to +60 °C
830003093BSPEC
4 files 4.194304 ±30ppm 50 12 -10 up to +60 °C830003
830003099BSPEC
4 files 4.433619 ±20ppm 30 20 -10 up to +60 °C
830003102BSPEC
4 files 4.433619 ±30ppm 50 20 -10 up to +60 °C
830003110BSPEC
4 files 4.9152 ±20ppm 50 30 -10 up to +60 °C
830003115BSPEC
4 files 4.9152 ±30ppm 50 30 -20 up to +70 °C830003
830018153SPEC
4 files 4.9152 ±30ppm 50 16 -10 up to +60 °C830003
830028392SPEC
4 files 4.9152 ±30ppm 50 18 -20 up to +70 °C
830034439SPEC
4 files 4.9152 ±30ppm 50 16 -20 up to +70 °C
830003119BSPEC
4 files 5 ±30ppm 50 30 -10 up to +60 °C830003
830012312SPEC
4 files 5 ±30ppm 50 30 -10 up to +60 °C
830003127BSPEC
4 files 6 ±20ppm 50 30 -10 up to +60 °C
830003132BSPEC
4 files 6 ±30ppm 50 30 -10 up to +60 °C830003
830016788SPEC
4 files 6 ±30ppm 50 30 -10 up to +60 °C830003
830026900SPEC
4 files 6 ±20ppm 50 16 -10 up to +60 °C830003
830003134BSPEC
4 files 6.144 ±20ppm 50 30 -10 up to +60 °C
830003137BSPEC
4 files 6.144 ±30ppm 50 30 -10 up to +60 °C830003
830027527SPEC
4 files 7.175 ±50ppm 100 16 -55 up to +105 °C
830003329BSPEC
4 files 7.3728 ±20ppm 50 30 -10 up to +60 °C
830003334SPEC
4 files 7.3728 ±30ppm 50 16 -10 up to +60 °C830003
830003335BSPEC
4 files 7.3728 ±30ppm 50 30 -10 up to +60 °C
830003336BSPEC
4 files 7.3728 ±15ppm 30 18 -10 up to +60 °C830003
830010689SPEC
4 files 7.3728 ±30ppm 50 30 -10 up to +60 °C830003
830003147BSPEC
4 files 8 ±20ppm 50 30 -10 up to +60 °C
830003151SPEC
4 files 8 ±30ppm 50 16 -10 up to +60 °C830003
830003156BSPEC
4 files 8 ±30ppm 50 30 -20 up to +70 °C830003
830011301SPEC
4 files 8 ±30ppm 50 30 -10 up to +60 °C830003
830020423SPEC
4 files 8 ±30ppm 50 18 -20 up to +70 °C830003
830026380SPEC
4 files 8 ±30ppm 50 16 -20 up to +70 °C830002
830029914SPEC
4 files 8 ±30ppm 50 16 -40 up to +85 °C
830050510SPEC
4 files 8 ±30ppm 50 18 -40 up to +85 °C
830055663SPEC
4 files 8 ±20ppm 30 18 -40 up to +85 °C830002
830055901SPEC
4 files 8 ±20ppm 50 18 -20 up to +70 °C
830059082SPEC
4 files 8 ±20ppm 50 10 -20 up to +70 °C
NEW830106162701SPEC
4 files 8 ±20ppm 30 16 -40 up to +85 °C
NEW830108313809SPEC
4 files 8 ±30ppm 50 12 -40 up to +85 °C
830003271BSPEC
4 files 8.192 ±30ppm 50 30 -10 up to +60 °C
830026902SPEC
4 files 8.192 ±20ppm 50 16 -10 up to +60 °C
830061486SPEC
4 files 8.192 ±30ppm 50 10 -40 up to +85 °C
830003277BSPEC
4 files 9.8304 ±20ppm 50 30 -10 up to +60 °C
830003279BSPEC
4 files 9.8304 ±30ppm 50 30 -10 up to +60 °C
830026904SPEC
4 files 9.8304 ±20ppm 50 16 -10 up to +60 °C
830003164BSPEC
4 files 10 ±20ppm 50 30 -10 up to +60 °C
830003166SPEC
4 files 10 ±30ppm 50 16 -10 up to +60 °C830003
830003169BSPEC
4 files 10 ±30ppm 50 30 -20 up to +70 °C830003
830017145SPEC
4 files 10 ±30ppm 50 30 -10 up to +60 °C830003
830021675SPEC
4 files 10 ±30ppm 50 18 -20 up to +70 °C
830032341BSPEC
4 files 10 ±30ppm 50 18 -20 up to +70 °C
830056583SPEC
4 files 10 ±30ppm 30 12 -40 up to +85 °C
830072402SPEC
4 files 10 ±20ppm 30 18 -40 up to +85 °C830002
NEW830108338709SPEC
4 files 10 ±20ppm 50 12 -40 up to +105 °C
830003327BSPEC
4 files 11 ±20ppm 30 30 -10 up to +60 °C
830003515BSPEC
4 files 11.0592 ±20ppm 30 20 -10 up to +60 °C
830003519SPEC
4 files 11.0592 ±30ppm 50 16 -10 up to +60 °C830003
830003523BSPEC
4 files 11.0592 ±30ppm 50 30 -20 up to +70 °C830003
830018496BSPEC
4 files 11.0592 ±30ppm 50 18 -20 up to +70 °C
830026382SPEC
4 files 11.0592 ±30ppm 50 16 -20 up to +70 °C830002
830028928SPEC
4 files 11.0592 ±30ppm 50 20 -20 up to +70 °C
830003206BSPEC
4 files 12 ±20ppm 30 30 -10 up to +60 °C
830003210SPEC
4 files 12 ±30ppm 50 16 -10 up to +60 °C830003
830003215BSPEC
4 files 12 ±30ppm 50 30 -20 up to +70 °C830003
830010043SPEC
4 files 12 ±30ppm 50 30 -10 up to +60 °C
830026384SPEC
4 files 12 ±30ppm 50 16 -20 up to +70 °C830002
830032878SPEC
4 files 12 ±50ppm 50 18 -10 up to +60 °C
830033580SPEC
4 files 12 ±30ppm 50 18 -20 up to +70 °C
830035293SPEC
4 files 12 ±30ppm 50 16 -40 up to +85 °C830003
830036401SPEC
4 files 12 ±20ppm 50 18 -20 up to +70 °C
830055295SPEC
4 files 12 ±20ppm 30 18 -40 up to +85 °C830002
830055999SPEC
4 files 12 ±30ppm 30 18 -40 up to +85 °C
830056346SPEC
4 files 12 ±30ppm 30 18 -40 up to +85 °C
830059522SPEC
4 files 12 ±20ppm 30 18 -40 up to +85 °C830002
830061647SPEC
4 files 12 ±20ppm 30 12 -40 up to +85 °C
830070868SPEC
4 files 12 ±10ppm 20 18 -40 up to +85 °C
830069944SPEC
4 files 12 ±20ppm 30 15 -40 up to +85 °C
830069882SPEC
4 files 12 ±30ppm 100 10 -40 up to +125 °C830002
830108206909SPEC
4 files 12 ±10ppm 20 8 -40 up to +85 °C
NEW830105420809SPEC
4 files 12 ±10ppm 10 10 -20 up to +70 °C
NEW830108338809SPEC
4 files 12 ±20ppm 30 12 -40 up to +105 °C
830003286BSPEC
4 files 12.288 ±30ppm 50 30 -10 up to +60 °C
830059523SPEC
4 files 12.288 ±20ppm 30 18 -40 up to +85 °C830002
830061648SPEC
4 files 12.288 ±20ppm 30 12 -40 up to +85 °C
830056556SPEC
4 files 12.5 ±50ppm 50 18 -40 up to +85 °C
830059477SPEC
4 files 12.8 ±10ppm 20 15 -40 up to +85 °C830002
830031646BSPEC
4 files 13 ±30ppm 50 18 -20 up to +70 °C
830082070SPEC
4 files 13.56 ±10ppm 20 8 -40 up to +85 °C
NEW830105961109SPEC
4 files 13.56 ±20ppm 30 18 -40 up to +85 °C
NEW830106163301SPEC
4 files 13.56 ±20ppm 30 16 -40 up to +85 °C
830003200BSPEC
4 files 14.31818 ±30ppm 50 30 -20 up to +70 °C
830026386SPEC
4 files 14.31818 ±30ppm 50 16 -20 up to +70 °C
830033643SPEC
4 files 14.31818 ±50ppm 50 18 -10 up to +60 °C830002
830059526SPEC
4 files 14.31818 ±20ppm 30 18 -40 up to +85 °C
830105961309SPEC
4 files 14.31818 ±20ppm 30 18 -40 up to +85 °C
830003218BSPEC
4 files 14.7456 ±20ppm 30 30 -10 up to +60 °C
830003224BSPEC
4 files 14.7456 ±30ppm 50 30 -10 up to +60 °C830003
830012313SPEC
4 files 14.7456 ±30ppm 50 30 -10 up to +60 °C830003
830026388SPEC
4 files 14.7456 ±30ppm 50 16 -20 up to +70 °C830002
830026908SPEC
4 files 14.7456 ±20ppm 50 16 -10 up to +60 °C830003
830033328SPEC
4 files 14.7456 ±50ppm 50 18 -10 up to +60 °C
830036956SPEC
4 files 14.7456 ±30ppm 50 16 -20 up to +70 °C
830055293SPEC
4 files 14.7456 ±20ppm 30 18 -40 up to +85 °C830002
830072403SPEC
4 files 14.7456 ±20ppm 30 18 -40 up to +85 °C
830003231BSPEC
4 files 16 ±20ppm 30 30 -10 up to +60 °C
830003237SPEC
4 files 16 ±30ppm 50 16 -10 up to +60 °C830003
830003240BSPEC
4 files 16 ±30ppm 50 30 -20 up to +70 °C830003
830011263SPEC
4 files 16 ±30ppm 50 30 -10 up to +60 °C
830015055SPEC
4 files 16 ±30ppm 50 20 -10 up to +60 °C
830026392SPEC
4 files 16 ±30ppm 50 16 -20 up to +70 °C830002
830029370SPEC
4 files 16 ±30ppm 50 18 -20 up to +70 °C
830030819SPEC
4 files 16 ±50ppm 50 18 -10 up to +60 °C830002
830034122SPEC
4 files 16 ±20ppm 20 12 -20 up to +70 °C
830035264SPEC
4 files 16 ±50ppm 50 16 -10 up to +60 °C
830036034SPEC
4 files 16 ±30ppm 50 16 -40 up to +85 °C
830051235SPEC
4 files 16 ±30ppm 50 18 -40 up to +85 °C
830055951SPEC
4 files 16 ±20ppm 30 18 -40 up to +85 °C830002
830058383BSPEC
4 files 16 ±30ppm 50 20 -40 up to +85 °C
830064296SPEC
4 files 16 ±20ppm 20 8 -10 up to +70 °C830002
830069392SPEC
4 files 16 ±20ppm 20 10 -40 up to +85 °C830002
830100965009SPEC
4 files 16 ±10ppm 20 16 -40 up to +85 °C
830108207109SPEC
4 files 16 ±10ppm 20 8 -40 up to +85 °C
830108178109SPEC
4 files 16 ±10ppm 20 8 -40 up to +85 °C
NEW830107878109SPEC
4 files 16 ±30ppm 50 12 -40 up to +125 °C
NEW830108288709SPEC
4 files 16 ±10ppm 30 10 -40 up to +105 °C
830035503SPEC
4 files 16.384 ±50ppm 50 16 -10 up to +60 °C830002
830059528SPEC
4 files 16.384 ±20ppm 30 18 -40 up to +85 °C
830069395SPEC
4 files 16.384 ±20ppm 20 10 -40 up to +85 °C830002
830105961509SPEC
4 files 16.384 ±20ppm 30 18 -40 up to +85 °C
830063075SPEC
4 files 17.2032 ±30ppm 50 22 -40 up to +85 °C
830003298BSPEC
4 files 17.73447 ±20ppm 30 30 -10 up to +60 °C
830003174BSPEC
4 files 18.432 ±20ppm 50 -10 up to +60 °C
830003176BSPEC
4 files 18.432 ±30ppm 50 30 -20 up to +70 °C
830015023SPEC
4 files 18.432 ±30ppm 50 30 -20 up to +70 °C
830026911SPEC
4 files 18.432 ±20ppm 50 16 -10 up to +60 °C830003
830059529SPEC
4 files 18.432 ±20ppm 30 18 -40 up to +85 °C
830069400SPEC
4 files 18.432 ±20ppm 20 18 -40 up to +85 °C830002
830105961709SPEC
4 files 18.432 ±20ppm 30 18 -40 up to +85 °C
830069404SPEC
4 files 19.2 ±20ppm 20 10 -40 up to +85 °C830002
830108208009SPEC
4 files 19.2 ±10ppm 10 10 -20 up to +70 °C
830003309BSPEC
4 files 19.6608 ±30ppm 50 30 -10 up to +60 °C
830003177BSPEC
4 files 20 ±20ppm 50 30 -10 up to +60 °C
830003179BSPEC
4 files 20 ±20ppm 30 -10 up to +60 °C
830003181SPEC
4 files 20 ±30ppm 50 16 -10 up to +60 °C830003
830003185BSPEC
4 files 20 ±30ppm 50 12 -20 up to +70 °C830003
830003186BSPEC
4 files 20 ±30ppm 50 20 -10 up to +60 °C
830017146SPEC
4 files 20 ±30ppm 50 30 -10 up to +60 °C830003
830020131SPEC
4 files 20 ±30ppm 50 18 -20 up to +70 °C
830026394SPEC
4 files 20 ±30ppm 50 16 -20 up to +70 °C830002
830028710SPEC
4 files 20 ±30ppm 50 18 -40 up to +85 °C
830034225SPEC
4 files 20 ±50ppm 50 16 -30 up to +80 °C
830035265SPEC
4 files 20 ±50ppm 50 16 -10 up to +60 °C
830056808SPEC
4 files 20 ±20ppm 30 18 -40 up to +85 °C830002
830059585SPEC
4 files 20 ±15ppm 20 10 -40 up to +85 °C830002
830059638SPEC
4 files 20 ±20ppm 30 18 -40 up to +85 °C830002
830061856SPEC
4 files 20 ±10ppm 10 18 -20 up to +70 °C
830069381SPEC
4 files 20 ±20ppm 20 10 -40 up to +85 °C830002
830108207209SPEC
4 files 20 ±10ppm 20 8 -40 up to +85 °C
830108208109SPEC
4 files 20 ±10ppm 10 10 -20 up to +70 °C
830003312BSPEC
4 files 22.1184 ±20ppm 50 -10 up to +60 °C
830003325BSPEC
4 files 24 ±30ppm 50 30 -10 up to +60 °C830003
830012504SPEC
4 files 24 ±30ppm 50 16 -10 up to +60 °C830003
830026548SPEC
4 files 24 ±30ppm 50 18 -20 up to +70 °C
830032817SPEC
4 files 24 ±50ppm 50 18 -10 up to +60 °C
830035266SPEC
4 files 24 ±50ppm 50 16 -10 up to +60 °C
830036533SPEC
4 files 24 ±30ppm 50 18 -40 up to +85 °C830003
830053798SPEC
4 files 24 ±10ppm 25 18 -40 up to +85 °C
830058124SPEC
4 files 24 ±20ppm 30 18 -40 up to +85 °C830002
830058149SPEC
4 files 24 ±10ppm 10 10 -20 up to +70 °C830002
830059530SPEC
4 files 24 ±20ppm 30 18 -40 up to +85 °C830002
830064703SPEC
4 files 24 ±20ppm 50 18 -40 up to +85 °C
830072539SPEC
4 files 24 ±15ppm 15 8 -20 up to +70 °C830002
830069383SPEC
4 files 24 ±20ppm 20 10 -40 up to +85 °C830002
830069493SPEC
4 files 24 ±15ppm 20 10 -40 up to +85 °C830002
830107006509SPEC
4 files 24 ±10ppm 15 9 -40 up to +85 °C
830108160801SPEC
4 files 24 ±10ppm 20 8 -40 up to +85 °C
830108207309SPEC
4 files 24 ±10ppm 20 8 -40 up to +85 °C
830108208209SPEC
4 files 24 ±10ppm 10 10 -20 up to +70 °C
830108212309SPEC
4 files 24 ±10ppm 15 8 -40 up to +85 °C
NEW830108340709SPEC
4 files 24 ±20ppm 50 12 -40 up to +105 °C
830003386BSPEC
4 files 24.576 ±20ppm 50 30 -10 up to +60 °C
830003387SPEC
4 files 24.576 ±30ppm 50 20 -10 up to +60 °C
830026396SPEC
4 files 24.576 ±30ppm 50 16 -20 up to +70 °C830002
830033644SPEC
4 files 24.576 ±50ppm 50 18 -10 up to +60 °C
830035267SPEC
4 files 24.576 ±50ppm 50 16 -10 up to +60 °C830002
830059531SPEC
4 files 24.576 ±20ppm 30 18 -40 up to +85 °C830002
830069387SPEC
4 files 24.576 ±20ppm 20 10 -40 up to +85 °C830002
830105957509SPEC
4 files 24.576 ±20ppm 30 18 -40 up to +85 °C
830010595SPEC
4 files 25 ±30ppm 50 16 -10 up to +60 °C830003
830033075SPEC
4 files 25 ±50ppm 50 18 -10 up to +60 °C
830035268SPEC
4 files 25 ±50ppm 50 16 -10 up to +60 °C830002
830051068SPEC
4 files 25 ±10ppm 10 9 -20 up to +70 °C
830054555SPEC
4 files 25 ±20ppm 20 20 -40 up to +85 °C
830055299SPEC
4 files 25 ±20ppm 30 18 -40 up to +85 °C830002
830055474SPEC
4 files 25 ±50ppm 50 16 -40 up to +85 °C
830056463SPEC
4 files 25 ±30ppm 50 18 -40 up to +85 °C
830059532SPEC
4 files 25 ±20ppm 30 18 -40 up to +85 °C830002
830059800SPEC
4 files 25 ±10ppm 10 10 -10 up to +60 °C
830072604SPEC
4 files 25 ±10ppm 20 8 -40 up to +85 °C830002
830063321SPEC
4 files 25 ±20ppm 50 18 -40 up to +85 °C
830063334SPEC
4 files 25 ±20ppm 20 10 -40 up to +85 °C830002
830068911SPEC
4 files 25 ±30ppm 50 18 -20 up to +70 °C
830069494SPEC
4 files 25 ±15ppm 20 10 -40 up to +85 °C830002
830108212509SPEC
4 files 25 ±10ppm 15 8 -40 up to +85 °C
830107871909SPEC
4 files 25 ±10ppm 10 10 -20 up to +70 °C
830108174209SPEC
4 files 25 ±10ppm 15 10 -40 up to +85 °C
830081609SPEC
4 files 25 ±10ppm 20 8 -40 up to +85 °C
NEW830105863709SPEC
4 files 25 ±30ppm 30 12 -40 up to +85 °C
NEW830108340809SPEC
4 files 25 ±20ppm 30 12 -40 up to +105 °C
830050991SPEC
4 files 26 ±20ppm 20 10 -40 up to +85 °C830002
830059591SPEC
4 files 26 ±15ppm 20 10 -40 up to +85 °C830002
830059643SPEC
4 files 26 ±20ppm 30 18 -40 up to +85 °C830002
830072404SPEC
4 files 26 ±20ppm 30 18 -40 up to +85 °C830002
830066742SPEC
4 files 26 ±15ppm 15 8 -20 up to +70 °C830002
830108161401SPEC
4 files 26 ±10ppm 20 8 -40 up to +85 °C
830108186509SPEC
4 files 26 ±10ppm 10 10 -20 up to +70 °C
830108212609SPEC
4 files 26 ±10ppm 15 8 -40 up to +85 °C
NEW830108340909SPEC
4 files 26 ±10ppm 20 12 -40 up to +105 °C
830057824SPEC
4 files 27 ±20ppm 30 18 -40 up to +85 °C830002
830072543SPEC
4 files
