| General Information | |
|---|---|
| Operating Temperature | -40 °C up to +85 °C |
| Material Properties | |
|---|---|
| Frame Material | PA66 |
| Frame Flammability Rating | UL94 V-0 |
| Frame Color | Grey |
| Actuator Material | PA66 |
| Actuator Flammability Rating | UL94 V-0 |
| Actuator Color | Red |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Terminal Material | Copper Alloy |
| Terminal Plating | Gold |
| Electrical Properties | |
|---|---|
| IR | 300 mA |
| VR | 24 V (DC) |
| Contact Resistance Initial | 30 mΩ |
| RISO | 10000 MΩ |
| Withstanding Voltage | 500 V (AC) |
| Mechanical Properties | |
|---|---|
| Electrical Life | 2000 Steps |
| Connection Type | Opposite Side Connection |
Products
| Order Code | Datasheet | Downloads | Status | Operation Force (g) | Schematic | Packaging | Demoboard | Design Kit | Samples | |
|---|---|---|---|---|---|---|---|---|---|---|
 | 450301014042 | SPEC PCN pendingDue to a pending PCN there will be a new datasheet revision issued for this order code soon. Please find the actual as well based on valid PCN date the new revision datasheet below. If you have further questions please get in contact with our sales staff. | 5 files | Active i| Production is active. Expected lifetime: >10 years. | 800 | SPDT | Bulk | 9999003 | 499001 |
| Order Code | Datasheet | |
|---|---|---|
| 450301014042 | SPEC PCN pendingDue to a pending PCN there will be a new datasheet revision issued for this order code soon. Please find the actual as well based on valid PCN date the new revision datasheet below. If you have further questions please get in contact with our sales staff. |
| Samples |
|---|
| Order Code | Datasheet | Downloads | Status | Operation Force (g) | Schematic | Packaging | Demoboard | Design Kit | Samples |
|---|
