| Material Properties | |
|---|---|
| Cover Material | Stainless Steel |
| Mechanical Properties | |
|---|---|
| Stroke | 0.25 mm |
| Properties | |
|---|---|
| Actuator Material | LCP |
| Actuator Flammability Rating | UL94 V-0 |
| Actuator Color | Black; Salmon; White |
| Frame Material | LCP |
| Frame Flammability Rating | UL94 V-0 |
| Frame Color | Black |
| Contact Material | Stainless Steel |
| Contact Plating | Silver |
| Terminal Material | Copper Alloy |
| Terminal Plating | Silver |
| VR | 12 V (DC) |
| Contact Resistance Initial | 100 mΩ |
| Contact Resistance After Life Test | 2 Ω |
| RISO | 100 MΩ |
| Withstanding Voltage | 250 V (AC) |
| Qty. | 400; 550; 1000 |
| General Information | |
|---|---|
| Operating Temperature | -40 up to +85 °C |
| Packaging Properties | |
|---|---|
| Packaging | Tape and Reel |
Products
| Order Code | SPEC | Downloads | H
(mm) |
Operation Force
(g) |
Qty. | Design Kit | Samples |
|---|---|---|---|---|---|---|---|
| 430182043816 |
|
STE ALT EAG IGS CAD | 4.3 | 160 | 1000 |
499001
|
|
| 430152043826 |
|
STE ALT EAG IGS CAD | 4.3 | 260 | 1000 |
499001
|
|
| 430152043836 |
|
STE ALT EAG IGS CAD | 4.3 | 360 | 1000 |
499001
|
|
| 430182050816 |
|
STE ALT EAG IGS CAD | 5 | 160 | 1000 |
499001
|
|
| 430152050826 |
|
STE ALT EAG IGS CAD | 5 | 260 | 1000 |
499001
|
|
| 430152050836 |
|
STE ALT EAG IGS CAD | 5 | 360 | 1000 |
499001
|
|
| 430182070816 |
|
STE ALT EAG IGS CAD | 7 | 160 | 550 |
499001
|
|
| 430152070826 |
|
STE ALT EAG IGS CAD | 7 | 260 | 550 |
499001
|
|
| 430152070836 |
|
STE ALT EAG IGS CAD | 7 | 360 | 550 |
499001
|
|
| 430182080816 |
|
STE ALT EAG IGS CAD | 8 | 160 | 400 |
499001
|
|
| 430152080826 |
|
STE ALT EAG IGS CAD | 8 | 260 | 400 |
499001
|
|
| 430152080836 |
|
STE ALT EAG IGS CAD | 8 | 360 | 400 |
499001
|
|
| 430182095816 |
|
STE ALT EAG IGS CAD | 9.5 | 160 | 400 | – | |
| 430152095826 |
|
STE ALT EAG IGS CAD | 9.5 | 260 | 400 | – | |
| 430152095836 |
|
STE ALT EAG IGS CAD | 9.5 | 360 | 400 | – |
| Samples |
|---|
| Order Code | SPEC | Downloads | H
(mm) |
Operation Force
(g) |
Qty. | Design Kit | Samples |
|---|
