General Information |
---|
Operating Temperature | -30 °C up to +120 °C |
Compliance | RoHS |
Material Properties |
---|
Insulator Material | PA66 |
Insulator Flammability Rating | UL94 V-0 |
Insulator Color | Black |
Contact Material | Copper Alloy |
Contact Plating | Tin over Nickel |
Spring Material | INOX Steel |
Electrical Properties |
---|
IR UL | 20 A |
IR VDE | 10 A |
Working Voltage | 250 V (AC) |
Working Voltage [UL] | 250 V (AC) |
Working Voltage [VDE] | 250 V (AC) |
Withstanding Voltage [UL] | 1500 V (AC) |
Withstanding Voltage [cULus] | 1500 V (AC) |
Withstanding Voltage [VDE] | 3000 V (AC) |
Contact Resistance | 10 mΩ |
Contact Resistance [VDE] | 10 mΩ |
Mechanical Properties |
---|
Protection Class | I & II |
Fuse Size | 5x20 mm |
Certification |
---|
cULus Approval | E157417 |
VDE Approval | 133366 |
Packaging Properties |
---|
Packaging | Box |
Products
Too many results (XXX). Only the first 100 results are shown. Please narrow down your search.
Order Code | Datasheet |
---|
696211001102 | SPEC
|
