Design Kit WE-TDC SMT Shielded Coupled Inductor
Order Code 744894
Applications
- Non-Isolated Flyback Converter
- Buck or Boost with auxiliary winding
- BUCK-BOOST, SEPIC, ZETA & CUK Converter
- Switching regulators with second, unregulated output voltage
Products
Filter by
show in
article in 0 product lines
Reset allOrder Code | Datasheet | Simulation | Downloads | Status | Product series | L1(µH) | IR(A) | ISAT(A) | RDC1 typ(mΩ) | Size | Samples |
|---|---|---|---|---|---|---|---|---|---|---|---|
| WE-TDC SMT Shielded Coupled Inductor, 0.33 µH, 4 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 10.33 µH | Rated Current4 A | Saturation Current9 A | DC Resistance 111.1 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 0.39 µH, 4.5 A | Status NRNDi| Production is active. Product is not recommended for new design. Expected lifetime: 2-5 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 10.39 µH | Rated Current4.5 A | Saturation Current14 A | DC Resistance 111.6 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 0.68 µH, 3.3 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 10.68 µH | Rated Current3.3 A | Saturation Current6.5 A | DC Resistance 116.3 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 0.82 µH, 3.7 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 10.82 µH | Rated Current3.7 A | Saturation Current9.6 A | DC Resistance 115.9 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 1 µH, 2.85 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 11 µH | Rated Current2.85 A | Saturation Current5.1 A | DC Resistance 122.2 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 1.2 µH, 3.05 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 11.2 µH | Rated Current3.05 A | Saturation Current7.5 A | DC Resistance 120.2 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 1.8 µH, 2.85 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 11.8 µH | Rated Current2.85 A | Saturation Current5.8 A | DC Resistance 125.5 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 2.2 µH, 1.9 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 12.2 µH | Rated Current1.9 A | Saturation Current3.5 A | DC Resistance 149.5 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 2.7 µH, 1.85 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 12.7 µH | Rated Current1.85 A | Saturation Current3 A | DC Resistance 169.5 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 3.9 µH, 1.6 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 13.9 µH | Rated Current1.6 A | Saturation Current2.55 A | DC Resistance 182 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 4.7 µH, 1.85 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 14.7 µH | Rated Current1.85 A | Saturation Current4.2 A | DC Resistance 154.5 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 5.6 µH, 1.45 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 15.6 µH | Rated Current1.45 A | Saturation Current2.2 A | DC Resistance 1114 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 6.8 µH, 1.25 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 16.8 µH | Rated Current1.25 A | Saturation Current2 A | DC Resistance 1128 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 6.8 µH, 1.45 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 16.8 µH | Rated Current1.45 A | Saturation Current3.2 A | DC Resistance 188 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 10 µH, 1 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 110 µH | Rated Current1 A | Saturation Current1.65 A | DC Resistance 1190 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 10 µH, 1.35 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 110 µH | Rated Current1.35 A | Saturation Current2.6 A | DC Resistance 1113 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 12 µH, 0.95 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 112 µH | Rated Current0.95 A | Saturation Current1.55 A | DC Resistance 1202 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 12 µH, 1.3 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 112 µH | Rated Current1.3 A | Saturation Current2.3 A | DC Resistance 1117 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 15 µH, 0.85 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 115 µH | Rated Current0.85 A | Saturation Current1.25 A | DC Resistance 1262 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 15 µH, 1.1 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 115 µH | Rated Current1.1 A | Saturation Current2.2 A | DC Resistance 1165 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 18 µH, 0.8 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 118 µH | Rated Current0.8 A | Saturation Current1.2 A | DC Resistance 1345 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 18 µH, 1.05 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 118 µH | Rated Current1.05 A | Saturation Current1.9 A | DC Resistance 1179 mΩ | Size8038 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 22 µH, 0.7 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 122 µH | Rated Current0.7 A | Saturation Current1.1 A | DC Resistance 1435 mΩ | Size8018 | ||||
| WE-TDC SMT Shielded Coupled Inductor, 22 µH, 1 A | Status Activei| Production is active. Expected lifetime: >10 years. | Product seriesWE-TDC SMT Shielded Coupled Inductor | Inductance 122 µH | Rated Current1 A | Saturation Current1.8 A | DC Resistance 1203 mΩ | Size8038 |
