Material Properties | |
---|---|
Insulator Material | PBT |
Insulator Flammability Rating | UL94 V-0 |
Insulator Color | Black |
Contact Material | Copper Alloy |
Contact Plating | Selective Gold |
Contact Type | Stamped |
General Information | |
---|---|
Operating Temperature | -40 °C up to +105 °C |
Working Voltage | 250 V (AC) |
Withstanding Voltage | 500 V (AC) |
Contact Resistance | 20 mΩ |
RISO | 1000 MΩ |
Pitch | 2 mm |
Gender | Female |
Certification | |
---|---|
UL Approval | E323964 |
Packaging Properties | |
---|---|
Packaging | Tray |
Products
Order Code | Datasheet | Downloads | Pins | Pitch (mm) | Gender | L (mm) | IR (A) | Working Voltage (V (AC)) | Contact Resistance (mΩ) | Tol. R | Packaging | Design Kit | Samples |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
62501023021 | SPEC | 3 files | 10 | 2 | Female | 15.2 | 1 | 250 | 20 | max. | Tray | 612001 612690 | |
62501423021 | SPEC | 3 files | 14 | 2 | Female | 19.2 | 1 | 250 | 20 | max. | Tray | 612001 | |
62501623021 | SPEC | 3 files | 16 | 2 | Female | 21.2 | 1 | 250 | 20 | max. | Tray | 612001 | |
62502023021 | SPEC | 3 files | 20 | 2 | Female | 25.2 | 1 | 250 | 20 | max. | Tray | 612001 | |
62502423021 | SPEC | 3 files | 24 | 2 | Female | 29.2 | 1 | 250 | 20 | max. | Tray | – | |
62502623021 | SPEC | 3 files | 26 | 2 | Female | 31.2 | 1 | 250 | 20 | max. | Tray | 612001 | |
62503023021 | SPEC | 3 files | 30 | 2 | Female | 35.2 | 1 | 250 | 20 | max. | Tray | 612001 | |
62503423021 | SPEC | 3 files | 34 | 2 | Female | 39.2 | 1 | 250 | 20 | max. | Tray | 612001 | |
62504023021 | SPEC | 3 files | 40 | 2 | Female | 45.2 | 1 | 250 | 20 | max. | Tray | 612001 | |
62504423021 | SPEC | 3 files | 44 | 2 | Female | 49.2 | 1 | 250 | 20 | max. | Tray | – | |
62505023021 | SPEC | 3 files | 50 | 2 | Female | 55.2 | 1 | 250 | 20 | max. | Tray | 612001 |
Order Code | Datasheet |
---|---|
62501023021 | SPEC |
62501423021 | SPEC |
62501623021 | SPEC |
62502023021 | SPEC |
62502423021 | SPEC |
62502623021 | SPEC |
62503023021 | SPEC |
62503423021 | SPEC |
62504023021 | SPEC |
62504423021 | SPEC |
62505023021 | SPEC |
Samples |
---|
Order Code | Datasheet | Downloads | Pins | Pitch (mm) | Gender | L (mm) | IR (A) | Working Voltage (V (AC)) | Contact Resistance (mΩ) | Tol. R | Packaging | Design Kit | Samples |
---|
