| Kind Properties | |
|---|---|
| Gender | Socket |
| Type | Push & Pull |
| Material Properties | |
|---|---|
| Insulator Material | LCP |
| Insulator Flammability Rating | UL94 V-0 |
| Insulator Color | Black |
| Contact Material | Copper Alloy |
| Contact Plating | Selective Gold |
| Contact Type | Stamped |
| Shielding Material | Copper Alloy |
| Shielding Plating | Nickel |
| General Information | |
|---|---|
| Operating Temperature | -25 up to +85 °C |
| Electrical Properties | |
|---|---|
| Working Voltage | 100 V (AC) |
| Withstanding Voltage | 500 V (AC) |
| Contact Resistance | 100 mΩ |
