| General Information | |
|---|---|
| Operating Temperature | -25 °C up to +85 °C |
| Gender | Socket |
| Type | Hinge |
| Material Properties | |
|---|---|
| Insulator Material | LCP |
| Insulator Flammability Rating | UL94 V-0 |
| Insulator Color | Black |
| Contact Material | Copper Alloy |
| Contact Plating | Selective Gold |
| Contact Type | Stamped |
| Shielding Material | Stainless Steel |
| Electrical Properties | |
|---|---|
| Working Voltage | 100 V (AC) |
| Withstanding Voltage | 500 V (AC) |
| Contact Resistance | 100 mΩ |
Products
| Order Code | Datasheet | Downloads | Pins | Gender | Type | Mount | Operating Temperature | Working Voltage (V (AC)) | Design Kit | Samples |
|---|---|---|---|---|---|---|---|---|---|---|
| 693072010801 | SPEC | 6 files | 8 | Socket | Hinge | SMT | -25 °C up to +85 °C | 100 | 612690 614001 |
| Order Code | Datasheet |
|---|---|
| 693072010801 | SPEC |
| Samples |
|---|
| Order Code | Datasheet | Downloads | Pins | Gender | Type | Mount | Operating Temperature | Working Voltage (V (AC)) | Design Kit | Samples |
|---|
