General Information | |
---|---|
Pitch | 1 mm |
Material Properties | |
---|---|
Insulator Material | LCP |
Contact Material | Phosphor Bronze |
Contact Plating | 2.032µm Tin over 1.27µm Nickel |
Contact Type | Stamped |
Solder Tabs | Brass |
Products
Order Code | Datasheet | Downloads | Pins | Pitch (mm) | Type | L (mm) | IR (A) | Working Voltage (V (AC)) | Packaging | Contact Resistance (mΩ) | Tol. R | Design Kit | Samples |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
686104188622 | SPEC | 7 files | 4 | 1 | Horizontal | 7.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686106188622 | SPEC | 7 files | 6 | 1 | Horizontal | 9.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686108188622 | SPEC | 7 files | 8 | 1 | Horizontal | 11.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686109188622 | SPEC | 7 files | 9 | 1 | Horizontal | 12.8 | 1 | 125 | Tape and Reel | 30 | max. | – | |
686110188622 | SPEC | 7 files | 10 | 1 | Horizontal | 13.8 | 1 | 125 | Tape and Reel | 30 | max. | 612690 687001 | |
686112188622 | SPEC | 7 files | 12 | 1 | Horizontal | 15.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686114188622 | SPEC | 7 files | 14 | 1 | Horizontal | 17.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686116188622 | SPEC | 7 files | 16 | 1 | Horizontal | 19.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686118188622 | SPEC | 7 files | 18 | 1 | Horizontal | 21.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686120188622 | SPEC | 7 files | 20 | 1 | Horizontal | 23.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686122188622 | SPEC | 7 files | 22 | 1 | Horizontal | 25.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686124188622 | SPEC | 7 files | 24 | 1 | Horizontal | 27.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686126188622 | SPEC | 7 files | 26 | 1 | Horizontal | 29.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686128188622 | SPEC | 7 files | 28 | 1 | Horizontal | 31.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 | |
686130188622 | SPEC | 6 files | 30 | 1 | Horizontal | 33.8 | 1 | 125 | Tape and Reel | 30 | max. | 687001 |
Order Code | Datasheet |
---|---|
686104188622 | SPEC |
686106188622 | SPEC |
686108188622 | SPEC |
686109188622 | SPEC |
686110188622 | SPEC |
686112188622 | SPEC |
686114188622 | SPEC |
686116188622 | SPEC |
686118188622 | SPEC |
686120188622 | SPEC |
686122188622 | SPEC |
686124188622 | SPEC |
686126188622 | SPEC |
686128188622 | SPEC |
686130188622 | SPEC |
