| Kind Properties | |
|---|---|
| Pitch | 0.5 mm |
| Material Properties | |
|---|---|
| Insulator Material | LCP |
| Contact Material | Phosphor Bronze |
| Contact Plating | 120 (µ") Tin over 30 (µ") Nickel |
| Contact Type | Stamped |
| Solder Tabs | Brass |
Products
| Order Code | SPEC | Downloads | Pins | Pitch
(mm) |
Type | L
(mm) |
IR
(A) |
Working Voltage
(V (AC)) |
Packaging | Contact Resistance
(mΩ) |
Tol. R | Design Kit | Samples |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 687106183622 |
|
IGE STE 3D ALT EAG PRE CAD | 6 | 0.5 | Horizontal | 8.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687108183622 |
|
IGE STE 3D ALT EAG PRE CAD | 8 | 0.5 | Horizontal | 9.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687110183622 |
|
IGE STE 3D ALT EAG PRE CAD | 10 | 0.5 | Horizontal | 10.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687112183622 |
|
STE 3D ALT EAG PRE CAD | 12 | 0.5 | Horizontal | 11.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687114183622 |
|
IGE STE 3D ALT EAG PRE CAD | 14 | 0.5 | Horizontal | 12.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687116183622 |
|
IGE STE 3D ALT EAG PRE CAD | 16 | 0.5 | Horizontal | 13.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687118183622 |
|
IGE STE 3D ALT EAG PRE CAD | 18 | 0.5 | Horizontal | 14.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687120183622 |
|
IGE STE 3D ALT EAG PRE CAD | 20 | 0.5 | Horizontal | 15.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687122183622 |
|
IGE STE 3D ALT EAG PRE CAD | 22 | 0.5 | Horizontal | 16.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687124183622 |
|
STE 3D ALT EAG PRE CAD | 24 | 0.5 | Horizontal | 17.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687126183622 |
|
3D ALT EAG PRE CAD | 26 | 0.5 | Horizontal | 18.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687128183622 |
|
IGE STE 3D ALT EAG PRE CAD | 28 | 0.5 | Horizontal | 19.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687130183622 |
|
IGE STE 3D ALT EAG PRE CAD | 30 | 0.5 | Horizontal | 20.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687132183622 |
|
IGE STE 3D ALT EAG PRE CAD | 32 | 0.5 | Horizontal | 21.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687133183622 |
|
IGE STE 3D ALT EAG PRE CAD | 33 | 0.5 | Horizontal | 22.2 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687134183622 |
|
IGE STE 3D ALT EAG PRE CAD | 34 | 0.5 | Horizontal | 22.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
|
| 687140183622 |
|
IGE STE 3D ALT EAG PRE CAD | 40 | 0.5 | Horizontal | 25.7 | 0.4 | 50 | Tape and Reel | 30 | max. |
687001
|
